Home > Industrial Equipment & Components > Heater & Heat Exchanger > Heat Exchanger > Rotary Evaporator Used for Laboratory
US$ 3,000 - 15,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Pharmaceutical Processing
Power Source:
Electric
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Application
Pharmaceutical Processing
Power Source
Electric
Process
Vacuum Distillation
Brand Name
CAREDDI
Model Number
RE-20
Voltage
220V/50HZ
Power(W)
120W
Dimension(L*W*H)
650*470*550mm
Weight
45kg
Certification
CE ISO
Warranty
1 Year Guarantee
After-sales Service Provided
Engineers available to service machinery overseas
Rotary evaporator used for laboratory Description
Features
1.This machine adopts advanced frequency conversion technology and electronic speed regulation, which can ensure the stable operation of the motor. So this machine has high evaporation rate, high recovery.
2. The bath pot can reduce the damage in the lifting process. During the evaporation of low boilling point, collecting bottle can be immersed in bath, which can reduce the secondary evaporation.
3. The collecting bottle connected by mouth ball milling connection, easy loading and unloading, and it has high sealing.
4. High temperaturedurable seal, dynamic seal system has corrosion resistance and long life time, good air tightness under high temperature.
5. Using Japanese technology-AC inducction motor, stepless speed regulation, no brush, no spark, can work long time effectively.
6. Rotay evaporator chassis, bath, main rod, shaft are mde of high quality stainless steel, beautiful apprearance and corrosion resistance.
7. Intelligent temperature control, water and oil bath, more widely application. The temperature fluctuation is relatively small, only 0.2 C error. Evaporation is more stalbe, not easy to wash away the material.
8. The series of modular design, strong expanibility, easy installation, convenient maintenance.
Main Specifcations.
Model | RE-2L | RE-5L | RE-10L | RE-20L | RE-50L |
Evaporation bottle (L) | 2 | 5 | 10 | 20 | 50 |
Collection bottle(L) | 1 | 3 | 5 | 10+3 | 20+5 |
Oil heating power (KW) | 1.5 | 2.5 | 3 | 5 | 9 |
Oil heating temperature | Room air temperature-100℃ | Room air temperature-100℃ | Room air temperature-100℃ | Room air temperature-100℃ | Room air temperature-100℃ |
Vacuum pressure (Mpa) | Less than 0.1 | Less than 0.1 | Less than 0.1 | Less than 0.1 |
|
Rotation speed (RPM) | 10-180 | 10-180 | 5-110 | 5-110 | Less than 0.1 |
Evaporation rate (H2O)(L/H) | 1.2 | 2 | 3.5 | 5 | 8 |
Mixing motor power(W) | 60 | 90 | 120 | 120 | 180 |
Power phase | 2 phase | 2 phase | 2 phase | 2 phase | 2 phase |
SIZE(LXWXH) (mm) | 550X350X750 | 550X350X1100 | 1000x500x1800 | 1200X700X2200 | 1200x800x2200
|
