High capacity Pellet making machine

Specifications

1. High capacity
2. Low power consumption
3. Sealed without dust emission
4. 1-3mm granule size

 Carbon black Pelletizer System
1. System introduction
This system is to make round pellets from carbon black fine powder, and the pellet carbon black can be used in rubber and plastic industries as reinforcement agent and color pigment.
1) Pelletizing milled carbon black from Pyrolysis system
2) into the granule with the size of 1-3mm
3) Used as reinforcement agent and color pigment



2.  Specification

Sn	Part description	Power(kw)	Qty
1	Air Transmiter System	5	1
2	Main Pelletizer	36	1
3	Drum-Style Dryer	5.5	1
4	Elevator	4.5	3
5	Dust Collector	5	1
6	Auto Weighing Packager	10	1
7	Materail Storage Silo	35CBM	1
8	Total Power	66



3. Pictures and drawing





















       Plant layout
