Hot Sale Carbon Black Activation Machine

Specifications

1. Working long hours
2. Large capacity
3. HIgh efficiency
4. Good-seal and no dust emission
5.Easy operation

1. Application Fields

Available for modifying and depolymerizing the particles ranging from 325 mesh to nm, such as talc, ground limestone,  washed kaolin, calcined coal kaolin, quartz, mica, hydrafil, magnesium hydrate, brucite, superfine and precipitated barite, rubberlith, white carbon black, titanium pigment., ash fly, sericite and zinc oxide.



2. Advantage of production line

1) Continuous production, high production capacity.

2) High coating ratio, activation index and low consumption of modifying agent.

3) It has advantage of deagglomeration, there is no agglomerated particle in the finished product, which can be packed directly after being modified.

4) Low energy consumes, modifying powder with self produced heat.

5) Modification temperature can be adjusted according to differe nt material characteristics.

6)It operates under negative pressure,assuring the environment free of mill dust

7)Independent fluied ,non-fluied system and operation steadily.





4. flow chart







1.feeding system



2.reagent feeder system



ating machine



4.cyclone



5.bag filter



6.draft fan



pressor



Specification:









No.	Name	Unit	Qty	Powder (KW)	Material
1	Feeding device	Set	1	0.75	Carbon stee
2	Coating machine	Set	1	18.5kw×3	Carbon steel,coating   parts is alloy steel
3	Cyclone	Set	1	0.75	Carbon steel
4	Bag filter	Set	1	0.75	Carbon steel
5	Draft fan	Set	1	7.5	Carbon steel
6	Electric cabinet	Set	1		Carbon steel
7	Connection pipes	Set	1		Carbon steel
8	Reagent box	Set	1		Carbon steel
	Handling capacity				Material :carbon black ,500-800 mesh,handling capacity is 400-600kg/h



Pictures:
