YN875 skid steer loader technical specifications:
1.Chinese Deutz diesel engine
2.Germany Rexroth hydraulic pump
3.Italy SAI brand hydraulic motor
4.Hydraulic control system
5.Close cabin
6.Heater
7.Hydraulic brake
8.Gear type transmission system
10.Bobcat type quick coupler
11.High flow output
Item |
description |
Item |
description |
Rated operating capacity (kg) |
1050 |
Hinge pin height (mm) |
3150 |
Tipping load (kg) |
2100 |
Total height (mm) |
2050 |
Bucket capacity(m3) |
0.55 |
Length with bucket (mm) |
3560 |
Hydraulic pump flow (L/min) |
75/125 |
Length without bucket (mm) |
2780 |
Engine power (hp) |
75 |
Width with bucket (mm) |
1900 |
Weight (kg) |
3500 |
Track width (mm) |
1500 |
Max travel speed (km/h) |
12/18 |
Wheelbase (mm) |
1185 |
Grade ability |
20 |
Ground clearance (mm) |
200 |
Tire |
12-16.5 |
Dumping angle |
40 |
Fuel/hyd oil capacity (L) |
90/90 |
Dumping height (mm) |
2450 |
Height at maximum extension |
4070 |
Maximum reach (mm) |
710 |
Optional:
1. Original Cummins engine +$3050
2. DongFeng Cummins engine +$1080
3. Air condition +$750
4. Solid tyre +$2,050.00/4pcs
Packing:
2 units/20' container
4 units/40' container
Delivery time: 20 days
Guarantee: 1 Year
