Corn Silage harvesting machine 4QZ-2800
1. It is used to harvest stalks of corns, oats, etc. for silage store.
2. It realizes non-row harvesting.
3. It’s mainly composed of header, feeding device, throwing device, engine, underpan, driving room, hydraulic system, electric system, etc.
4. It can completes harvesting, cutting and smashing, curlating, throwing and loading continuously during one operation.
5. It adopts high-speed diesel engine of direct injection combustion chamber. Its PTO is 220hp (260hp is optional)
6. Technical parameter:
Item |
Unit |
Technical Specifications |
Overall dimension(L*W*H) |
mm |
6800x3300x3800 6800x3500x3800 |
Working width |
mm |
2800/3000 |
Whole weight |
kg |
7895 |
Working speed |
Km/h |
≤5 |
Stubble height |
mm |
≤150 |
Cut length of straw |
mm |
10~35 |
Feeding roller quantity |
pc |
8 |
Diameter of cut roller |
mm |
635 |
Rotation speed of cut roller |
R/min |
782 |
Knife type of cut roller |
/ |
Flat knife |
Throw distance (max) |
m |
12 |
throw tub Scop of turn round |
/ |
270degree |
Height of throw |
m |
4.5 |
Motor |
/ |
NC6110ZLN2L/6CTA8.3-C260 |
Motor power |
Kw/hp |
160/190 or 220/260 |
Motor output rotation speed |
r/min |
2200 |
Wheel base(front) |
mm |
2410 |
Wheel base (rear) |
mm |
1600/1745-1945 |
Axle base |
mm |
2400 |
I gear |
Km/h |
1.21-3.26 |
II gear |
Km/h |
3.02-8.15 |
III gear |
Km/h |
7.9-19.32 |
Reverse gear |
Km/h |
2.93-8.72 |
