Specifications
Biomass small gasifiers for 3 kw generatorUsing crop straw and other agricultural wastes to make straw gases
Biomass small gasifiers for 3 kw generator
Introduction:
JXQ/TW series biomass gasifier is equipment to make full use of crops straw, agricultural waste etc to produce fuel gas. The equipment adopts biomass pyrolysis and gasification technology to R&D this epoch-making product, which can change the common straw, biomass materials into a clean gas, effectively solving the pollution to the environment because of the combustion of the straw, biomass materials, man-made destruction of forest resources and other social problems, protecting the ecological environment, favorable to save energy and improving the farmer's quality of life.
Specification:
Model |
Gas output ( m3/h) |
Gas calorific value |
Efficiency of gasification |
Draught fan Power |
Material consumption |
Generator Power |
TW-10A |
5-10 |
4600-5200KJ/m3 |
>72% |
220V50Hz(110V60Hz) |
3-5KG/H |
3kw |
JXQ-20 |
15-20 |
4600-5200KJ/m3 |
>72% |
220V50Hz(110V60Hz) |
8-10KG/H |
5kw |
JXQ-30 |
25-30 |
4600-5200KJ/m3 |
>72% |
220V50Hz(110V60Hz) |
15-18KG/H |
10kw |
|
TW-50A (Fixed bed) |
50m3/h |
4600-5200KJ/m3 |
>72% |
220V/380V |
25-40KG/H |
15KW |
|
TW-50B (Fluidized bed ) |
50m3/h |
4600-5200KJ/m3 |
>72% |
220V/380V |
25-40KG/H |
15KW |
|
TW-100A (Fixed bed) |
100m3/h |
4600-5200KJ/m3 |
>72% |
220V/380V |
50-60KG/H |
30KW |
Feature:
1.New design, advanced technology, scientific and compact structure, high efficiency, simple operation.
2.Only 2 minutes to generate gas. And it takes 8-12 minutes to boil 4.5kgs water same as the natural gas.
3.Feeding raw material, generating gas, using gas can realize simultaneously.
4.Good cleaning device to control the tar content, ash content, water content and guarantee the gas clean and good.
5.The occupy area is not over 1 square meter. Gasifying efficiency can get to 72%. The heat value of gas is 4600-5200KJ/m3.
6.And we can design the suitable power according to customer’s electricity situation.
Picture:
