Microcomputer Temperature Controller

Specifications

Microcomputer Temperature Controller
Features:
Switch between cooling, heating and alarming;return difference to control temp.

Microcomputer Temperature Controller
User parameter setting and administrant menu setting;

Temperature upper and lower limit;

Compressor work on schedule when sensor error;

Compressor delay time adjustable;

Temperature calibration;

Alarm and universal model.

Size:

Panel size:77.0×34.5(mm)

Mounting size: 71×29(mm)

Product size: 77.0×34.5×65.5(mm)

Max. Length of sensor cable: 100m

Technical Parameters:

Power supply:220VAC±10%12VAC/VDC, optional

Power consumption:  ≤5W

Temperature measuring range:-50~99ºC

Display Resolution: 0.11 when ≥100ºC

Temperature sensor accuracy: ±0.5ºC

Compressor delay protecting time: 0-30 minutes adjustable

Temperature calibration:-5~+5ºC

Compressor control output contact capacity:10A/240VAC(20A/240V opitonal)

Sensor:Dallas integrated temperature sensor

Password function to protect machine.
