Automatic Chain Link Welding Machine
US$ 10,000 - 40,000
/ Set
1 Set(Min. Order)
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | BOBO | |
| Model Number | BOW-250 | Condition | New | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
automatic chain link welding machine1-PLC control
2-Good quality
automatic chain link welding machine
Our automatic chain link welding machine based on German advanced technology, adopts two times resistance energized method to weld lifting chain made of weld low carbon alloy steel, chain link conveyor, rotation, welding, upsetting, trimming and other 19-steps.
Features of automatic chain link welding machine
- Automatic, stable and reliable
- Good performance
- Save enegy and improve welding quality
Main technical data of automatic chain link welding machine
| Machine model | BOW-250 |
| Wire diameter | φ11-φ16mm |
| Link pitch | 35-65mm |
| Production capacity | 16-33 (rings/min) |
| Transformers: | Intermediate frequency inverter direct power supply |
| Rated duty cycle | 50% |
| Nominal capacity | 250KVA |
| Rated power | 7.5kw |
| Rated rotary speed | Stepless speed regulation (with brake) |
| Controller | PLC (Mitsubishi) |
| Rotary encoder | 600 (turns/min) |
| Subprime no-load voltage | 4-10 adjustable (V) |
| Cooling water: | |
| Pressure | 0.15——0.3(Mpa) |
| Consumption | 30 (l/points) |
| Temperature | 15≤T≤25(°C) |
| Pneumatic: | |
| Supplying air pressure | ≥0.65(Mpa) |
| Working pressure | 0.45≤P≤0.65(Mpa) |
| Air consumption | 8 (liter each work cycle) |
| Power | 270(kw) |
| Machine size | 3100mm*1800mm*2600mm |
| Machine net weight | about 7T |
