Specifications
The wheel radial fatigue testing machine is used to test radial impact performance & simulate the crash motion of vehicle wheel
truck wheel radial fatigue testing machine
The radial wheel impact test machine is used to test radial impact performance and simulate the crash motion of vehicle wheels. It is designed and manufactured as per international standards.
Main technical data
1- Structure: vertical machine frame
2- Test wheel diameter range: 15″~24.5″
3- Test wheel width range: <15″
4- Test Load range: 1500~15000 kg, accuracy:±1%
5- Load method: hydraulic servo in closed-loop control; load accuracy: ±1%P.S.
6- Test speed range: 20~100km/h, accuracy: 0~+2km/h
7- Drum diameter × width:Φ1707.6×500mm
8- Drum residual imbalance:<5g
9- Digital counter capacity: 1.0×10 r
10- Load cell capacity: 20T
Key word: Wheel impact testing machine, wheel testing machine, impact tester, wheel radial fatigue testing machine, wheel cornering fatigue testing machine.
