Home > Manufacturing & Processing Machinery > Machine Tools > Punching Machine > Automatic Blanking Line
Automatic Blanking Line
US$ 1 - 2
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Power Source:
Mechanical
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Pneumatic Automatic Round CutterUS$ 6,000 - 8,000MOQ: 1 Set -
Pneumatic Automatic Rotary CuttingUS$ 6,000 - 8,000MOQ: 1 Set
-
High Performance Round Slitting Machine for SaleUS$ 4,500 - 10,000MOQ: 1 Set
-
High Performance Round Cutting Machine for SaleUS$ 4,500 - 10,000MOQ: 1 Set
-
High Performance Round Shape Slitting MachineUS$ 5,000 - 8,000MOQ: 1 Set
Condition
New
CNC or Not
Normal
Power Source
Mechanical
Place of Origin
Jiangsu, China
Brand Name
BOBO
Model Number
APL
Specifications
The automatic blanking line include decoiler, straightener, feeder, punching machine and recoiler,etc, used for continuous work.The automatic punching line, stamping line, blanking include decoiler, straightener, feeder, punching machine and recoiler,etc, used for continuous work.
Such automatic production line can be use for material blanking, profile forming, deep drawing, etc work with speical designed mould, die, tools.
I Production flow:
Decoiling and straightening machine → Pneumatic feeding device → punching machine
II Technical data
l Material: Steel plate in coil
l Available external diameter: 1200mm
l Available interior diameter: 508±10mm
l Width of steel strip: 250mm
l Thickness of steel strip: 0.6mm
l Weight of coil: ≤1200 kg
l Work speed: 48pieces/min
l Power: 380V±10%
l Air pressure: ≥0.5Mpa
