Spiral Flexible Aluminum Duct Making Machine
US$ 4,800 - 9,800
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Spiral duct forming machine
Pipe Material:
Aluminum
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Auto Produiton Line for Rectangle Air DuctUS$ 15,000 - 20,000MOQ: 1 Set -
Rectangle Squre Air Duct Production LineUS$ 15,000 - 20,000MOQ: 1 Set
-
Metal Sheet Beading MachineUS$ 2,200 - 3,600MOQ: 1 Set
-
Duct ZipperUS$ 15,000 - 28,000MOQ: 1 Set
-
TDF Flange Making MachineUS$ 4,000 - 6,000MOQ: 1 Set
Condition
New
Type
Other, Spiral duct forming machine
Pipe Material
Aluminum
Application
Other, air conditioning; ventilation
Production Capacity
up to 30m/min
Place of Origin
Jiangsu, China
Brand Name
BOBO
Model Number
PAD-300 series
Voltage
380V
Power(W)
0.75KW
Dimension(L*W*H)
1200X550X1200mm
Weight
260KG
Certification
CE, ISO
Warranty
One year since the date B/L.
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Spiral flexible aluminum duct making machine1- Automatic forming
2- Automatic cutting
3- Automatic compressing
Spiral flexible aluminum duct making machine
The Spiral flexible aluminum duct making machine is used to produce the fleixble aluminum duct, which is widely used for chimney, exhaust pipe, etc.
Feature
- Automatic forming speed can be adjustable
- Automatic online cutting device is optional
- Pneumatic compessing system is optional
Main technical data
| 1 | Diameter range | 60-300mm |
| 2 | Duct length | 100-8000mm |
| 3 | Pure aluminum foil size |
0.05-0.15mm thick 42-55mm wide |
| 4 | Forming speed | 1-5m/min |
| 5 | Main motor power | 0.75KW |
| 6 | Dimension | 1200 x 550 x 1200 mm |
| 7 | Weight | 260KG |
