Help CenterIndustrial Ultrasonic Atomizer
Related Products
Specifications
Atomize various kinds of liquidLarge atomizing volume, energy-saving, environmental protection
No plug, no abrasion
Quick Detail:
Atomize various kinds of liquid
Large atomizing volume, energy-saving, environmental protection
No plug, no abrasion
Description:
Ultrasonic spray (FOG) is to use the energy of ultrasonic water or liquid scattered, forming several microns to 100 microns in size of particles, used for air humidifying, granulating, mixing liquid, promote chemical reactions, spraying, molten metal powder etc..
Applications:
Atomization humidification, chemical mixing, production, spray drying granulation, paint spraying, metal milling and so on
Specifications:
Model |
YP-W51 |
YP-W55 |
YP-W57 |
YP-W59 |
YP-W61 |
YP-W63 |
Frequency |
60 KHz |
50 KHz |
40 KHz |
30 KHz |
20 KHz |
15 KHz |
Atomization Volume |
0.5 L/H |
2 L/H |
10 L/H |
70 L/H |
100 L/H |
150 L/H |
Average Particle Diameter of Fog |
20μm |
28μm |
32μm |
39μm |
51μm |
62μm |
Power Consumption |
0.01 Degrees/Kg |
0.001 Degrees/Kg |
||||
Atomization Head Structure |
Cylindrical |
Horn |
||||
Power |
30 W |
30 W |
60 W |
100 W |
300 W |
500 W |
The Application of Atomizing Media |
Ordinary water, a variety of liquid substances, chemical liquid, a variety of oil mucus, metal melt and so on |
|||||
Competitive Advantage:
A major breakthrough in spray technology, you can spray a variety of liquids.
Low power consumption, the fog of great energy saving.
No plug, no abrasion, no noise, no pressure, no moving parts.
Can be any combination to meet the requirements of the spray volume.
The use of high-performance titanium and stainless steel.
