Ultrasonic Processer for Biodiesel Application

 Ultraultrasonic processer for biodiesel application

Ultrasonic frequency is 2×10⁴ Hz10⁷ Hz which has exceeded the range of people can hear. When the ultrasonic transmits in the liquid, through mechanical, cavitate and heat function, it can produce mechanics, calorific, optics, electricity and chemistry reaction. Especially the high-power ultrasonic can produce strongly cavitate function, and then make the part form instantaneous high temperature, high voltage, vacuum and minute jet flow. For the chemistry, those cause a very good part small condition for reaction and improve reaction speed and reduce reaction condition. For biomass extract, those cause plant cell wall to break and liquid to immerse quickly, and make the extracted active principle can dissolve into the liquid quickly. This will improve rate of exaction, reduce time of exaction and save liquid.

Ultrasonic exaction frequency range is 20kKHz100kHz, about frequency 20kHz ultrasonic is used mostly. One reason is the ultrasonic frequency lower, the power is larger. Some one think this frequency is helpful for breaking the plant cell wall.

Basic structure

ultrasonic focusing probe type ultrasonic exaction system

Basic structure: oscillator system includes transducer, booster, horn (probe) and generator

Characteristic: the processed liquid need put into the container, and put the horn into the liquid, and then transmit ultrasonic. The processed liquid volume can large or small; the time can long or short. In general, ultrasonic intensity is not equality in the whole container, the nearer the horn, the stronger ultrasonic will be.

Frequency range: 15KHz20KHz28 KHz30 KHz35 KHz40 KHz50 KHz60 KHz

The lower frequency is, the larger per unite power will be; the higher frequency is, the lower per unite power will be.

Per unite nominal power: 0~3000W, power adjustable. Can be used many unites assembled.

Horn (probe) type and material can be made according to requirements..

Typical technical parameters(Other frequency and power structure can be customized with special requests)
