OEM supplied porous stick for hardened steel made of Tungsten carbide rod
Features of Tungsten carbide rod
As for tungsten carbide rod, below are the general features for your reference
For more details of specific type, please inform us:
1.Better wear resistance, higher toughness, better deformation and fracture resistance, results in a long life and good size accuracy
2.Adopt advanced automatic extrusion equipment
3.HIP sintering and precision grinding to ensure the good performance
4.Both blank and finished tungsten carbide rods available
5.Can reach a mirror effect surface after accurate grinding and polishing
Application:
They are mostly applied for drill bits, end mills, and reamers, non-ferrous precision cutting and wood cutting, fiberglass reinforced plastics, titanium alloys, hardened steel, etc.
Free smaple was available!
Main Grade for Tungsten carbide rods
| Grade/ Properties / Application | ||||||||
| Grade | Equal to ISO Category Number | Performance | Performance&application recommended | |||||
| Density | Bend Strength | Hardness | ||||||
| G/Cm 3 | N/mm 2 | HRA | ||||||
| YG6X | K10 | 14.8-15.1 | ≥1560 | ≥91.0 | Qualified for machining of chilled cast iron, alloy cast iron, refractory steel and alloy steel. Also Qualified for the machining of common cast iron. | |||
| YG6A | K10 | 14.7-15.1 | ≥1580 | ≥91.0 | ||||
| YG6 | K20 | 14.7-15.1 | ≥1670 | ≥89.5 | Qualified for finish machining and semi-finish machining for the cast iron, non-ferrous metal, alloy and unalloyed materials. Also qualified for wire drawing for the steel and non-ferrous metal, electric drill for geology use and steel drill etc. | |||
| YG8 | K30 | 14.6-14.9 | ≥1840 | ≥89 | Qualified for rough machining of cast iron, non-ferrous metal, nonmetal materials, drawing of steel, non-ferrous metal and pipes, various drills for geology use, tools for machine manufacture and wearing parts. | |||
| YG10X | 14.5 | 2400 | 91.5 | Fine grain alloy, good wear resistance,Used for processing hard | ||||
| wood, veneer board,PCB,PVC and metals. | ||||||||
| YL10.2 | 14.5 | 2400 | 91.8 | Forming or stamping dies for metal powders and nonmental powders. | ||||
| YG13X | 14.3 | 2600 | 89.5 | For oil cone dril bits, for medium soft and medium-hard rocks. | ||||
ZhuZhou HongTong Tungsten Carbide Co., Ltd., located at Liyu Industrial Park, Zhuzhou National High-tech Development Zone, is a high-tech joint-equity enterprise integrating R&D, production and marketing of cemented carbide series products.
The company sets up an independent production and R&D base, covering a total area of 7,000m2 and a plant area of 4,000m2. There is a group of experienced technical personnel and a staff of 80 people including 5 engineers, 8 assistant engineers, and 29 people having college degree or above. The company mainly produces cemented carbide drawing dies, cold heading dies, mining tools, sealing rings, and other nonstandard products, wherein the cemented carbide drawing dies and cold heading dies take a leading position in the industry, and the bore of wire-drawing die can be minimized to 0.1mm, deeply popular with customers.
