Home > Products > button inserts > Carbide Abrasive Burr

Carbide Abrasive Burr

FOB Price

US$ 40 - 45 / Kilogram

5 Kilograms(Min. Order)

Port Any port in china
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hunan, China		Brand Name	Lipai
Model Number	YK05,YG11C,YK20		Type	Power Tool Parts

Product Description

Our products including the following:

i.Powder metallurgy dies:

1.Non-Ferrous metal moulds: like gear finished die,sizing die,automobile parts,motor driven tool parts,etc.

2.Magnaglo moulds: like E shape dies,U shape dies,PM shape dies,G shape dies,etc.

3.Tungsten carbide moulds: like wire-drawing die,indexable inserts dies,mining tools dies,squeezing die,steel die,etc.

ii.Kinds of tungsten carbide TF products:

1.Tungsten carbide nonstandard dies: like cold heading dies,battery dies,carbide blanking dies,stretching die,etc.

2.Tungsten carbide wear parts:carbide rollers,carbide gauge,tungsten carbides inserts,carbide roll collar,carbide plug gauge,etc.

ii.Tungsten carbide products:carbide board,Bars,etc

If you are interested in our goods,please don't hesitate to contact us for further information.You shouldn't miss it!

Carbide mining bits

Grade introduction

Grade

Performance

Performance&application recommended

Density

Bend Strength

Hardness

G/Cm³

N/mm²

HRA

YG4C

15.1

1800

Mainly used as small buttoon ns for percussion bits to cut soft and medium

hard formations.

YG6

14.95

1900

90.5

For coring crowns,electric coal drill bits, coal cutting picks,oil cone bits and

scraping knife bits,used in geological prospecting,coal mining and oil well

boring.

YG8

14.6-14.9

≥1840

≥89

Qualified for rough machining of cast iron, non-ferrous metal, nonmetal materials, drawing of steel, non-ferrous metal and pipes, various drills for geology use, tools for machine manufacture and wearing parts.

YK05

14.95

2500

90.5

Mostly used as the buttons of small and medium sized percussion bits and as

YG8C

14.8

2400

88.5

the inserts of rotary prospecting bits to cut soft and medium hard formation.

YG9C

14.30-14.70

≥2200

≥87.5

it is suitable for making geological prospecting drill bits and mining inserts

for light electrical drills for drilling soft rok and coal formations and drill bits

for drilling un-silicated rock formations.

YK15

14.6

2450

87.6

Suitable to strips, conical buttons for rotary percussion-resistant,geological

prospectioin buttons, cut soft and medium hard formation.

YK20

14.4

2500

86.8

Primarily for the buttons and inserts of rotary percussion bits to cut

medium-hard and very hard formations.

YK25

14.4

2550

87.2

Primarily for the buttons and inserts of rotary percussion bits to cut

medium-hard and very hard formations.

YG11C

14.4

2700

86.5

Largely for the inserts and buttons of percussion bits and tricone bits to cut

medium-hard, hard and very hard formations.

YG13C

14.2

2850

Primarily for the buttons of tricone bits and inserts or rotary percussion bits to

cut hard and very hard formations.

YG15C

3000

85.5

For oil cone dril bits, for medium soft and medium-hard rocks.

YK40

14.10-14.30

≥2400

≥85.5

With super thoughness and corresponding wear resistance, it is suitable for

mining inserts in mine prospecting, in heavy duty rock drilling machines and

YK45

13.95-14.15

≥2200

≥85.5

depth drilling bits for drilling hard and super hard rock formations and it can

also be used for other button bits.

YK25

13.90-14.10

≥2360

≥85.0
