Sell Eagle WL1443A Wood Lathe Machinery

Name: Sell Eagle WL1443A Wood Lathe Machinery
Brand: EAGLE
SKU: 140925248
Availability: InStock

Eagle Industries, Ltd.

Negotiable MOQ: 5 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

Used

Place of Origin:

Shandong, China

Brand Name:

EAGLE

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Condition Used

Place of Origin Shandong, China

Brand Name EAGLE

Model Number sell eagle WL1443A Wood Lathe machinery

Power(W) 1100w

Weight 85/90(body) 45/48(stand)

Dimension(L*W*H) 1620*400*430mm

Specifications

1.sell eagle WL1443A Wood Lathe machinery
2The lathe WL1443 can be fitted with two cast iron stand,which will appeal more to th

sell eagle WL1443A Wood Lathe machinery

Feature:

The lathe WL1443A can be fitted with two cast iron stand, which will appeal more to the professional or committed hobby turner, who is looking for a more rugged and powerful machine. This cast iron stand also can be fitted to our model WL1236 turning lathe.
Notable features of this excellent lathe are:
The solid cast iron bead which can both slide to and fro along the bed lathe most convenient position and rotate to allow best assess for bowl turning.
Mechanical variable speed which provides a choice of ten speeds.
Heavy duty tool rest support.
300mm cast iron tool height adjustable tool rest with bowl turning extension.
Comes complete with four prong drive center, revolving tailstock center, 150mm face plate, center knock-out bar, faceplate spanner

Specification:

Model	WL 1443A
Motor(W)	1100
No of speed	Variable
Spindle speed(rpm)(50Hz)	500-2000
Spindle speed(rpm)(60Hz)	600-2400
Swing over bed	14" (360)
Distance between centers	43" (1100)
Drive spindle	1"8 RH thread or other
Headstock and tailstock taper	#2 morse or other
Face plate	6"
Tool rest	12"
N.G. weight(kgs)	85/90(body) 45/48(stand)
Packing size(mm)	1620x400x430(body)
Packing size(mm)	820x370x260(stand)
20"container(units)	75
Item No.	361021
