Wood LatheCE Standard
Wood Lathe
The lathe WL1443 can be fitted with two cast iron stand,which will appeal more to the professional or committed hobby turner, who is looking for a more rugged and powerfull machine.This cast iron stand also can be fitted to our model WL1236 turning lathe. Notable features of this excellent lathe are:
*The solid cast iron bead which can both slide to and fro along the bed lathe most convenient position and rotate to allow best assess for bowl turning.
*Mechanical variable speed which provides a choice of ten speeds.
*Heavy duty tool rest support.
*300mm cast iron tool height adjustable tool rest with bowl turning extension.
*Comes complete with four prong drive center, revolving tailstock center, 150mm face platek, center knock-out bar, faceplate spanner.
| Model | WL 1443 | WL 1443A |
| Motor(W) | 550/750 | 1100 |
| No of speed | Variable | |
| Spindle speed(rpm)(50Hz) | 500-2000 | |
| Spindle speed(rpm)(60Hz) | 600-2400 | |
| Swing over bed | 14" (360) | |
| Distance between centers | 43" (1100) | |
| Drive spindle | 1"8 RH thread or other | |
| Headstock and tailstock taper | #2 morse or other | |
| Face plate | 6" | |
| Tool rest | 12" | |
| N.G.weight(kgs) | 92/97 | 85/90(body) 45/48(stand) |
| Packing size(mm) | 1620x340x430 | 1620x400x430(body) 820x370x260(stand) |
| 20"container(units) | 110 | 75 |
| Item No. | 361020 | 361021 |
