WBS 689&WBS6108 Horizontal & vertical sanderSanding belt can be locked in at vertical,horizontal and any angle in between.
WBS 699 Horizontal & vertical sander
Specifications:
Horizontal & vertical sander | ||
Features |
1.Sanding belt can be locked in at vertical,horizontal and any angle in between. 2.Oscillating feature reduces heat built-up on sanding belt to reduce loading and burning . 3.Quick release lever and tracking control dial are conveninetly located for replacing and tracking belt. 4.Cast-iron table moves up and down by handwheel to provide fast,easy and accurate workpiece positioning. 5.Titling sanding head for sanding bevels,angles and belt surface. 6.Improved tilting locker prevents the wear-out. 7.Adjustable outer drum support table enable contour sanding. 8.4"dust port hooks up to your dust collection system for efficient dust removal. |
1.Powerful 2HP motor delivers smooth,consistent power on heavy duty sanding jobs. 2.Idler roller can be used for edge sanding of irregular shapes. 3.Quick-release belt tensioning for easier belt changing. 4.Front cast-iron sanding table can be moved up and down,forward and backward. 5.Adjustable head from 0°-90°. 6.Spindle sanding kit with three sizes of drums and collars for contour sanding. 7.Graphite sanding platen can tilt from 0° to 90° or any angle in between. |
Model |
WBS 689 |
WBS 6108 |
Motor |
1.5HP(1.1kw) |
1.5HP(1.1kw) |
Abrasive Belt Size(mm) |
2260x152 |
2743x152 |
Belt Speed |
3900FPM |
3150FPM |
Front Table Size(mm) |
812x177 |
905x305 |
Auxiliary Table Size |
305x250 |
290x259 |
Platen Tilting |
0°-90° |
0°-90° |
Table Adjustment |
80mm |
up and down:101mm |
forward and backward:121mm | ||
Oscillating Distance |
19mm |
19mm |
Sanding Drums |
/ |
38mm,51mm.76mm |
114mm | ||
Dust Collection Chute |
102mm |
102mm |
Overall Dimentions(mm) |
1280x630x1100 |
1600x800x1260 |
Weight(kgs) |
120 |
220 |
Item No. |
421200 |
421202 |
Standard Accessories |
Sanding Belt, Miter Gauge, Mobile Base |
|
