Drilling And Milling Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
Eagle
Model Number:
UDM
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Machines Milling and Drilling MachineNegotiableMOQ: 1 Set -
UDM50110 Universal Drilling And Milling MachineNegotiableMOQ: 1 Set
-
Drilling and Mililng MachineNegotiableMOQ: 1 Set
-
Drilling and Mililng Machine UDM SeriesNegotiableMOQ: 1 Set
-
Industrial Drilling Machine DX-16NegotiableMOQ: 20 Sets
Condition
New
Brand Name
Eagle
Model Number
UDM
Type
Other, Universal, Universal
CNC or Not
Normal
Certification
CE
Warranty
one year
Specifications
Universal Drilling And Milling Machine1.CE Standard
2,Good performance
3,Easy to operate
Universal Drilling And Milling Machine
1,Get the certificate of CE
2,Large market
3,Good performance
4,Easy to operate
UDM 50110A:Automatic spindle feed.
UDM 50110B:Table feed in X,Y direction through gear drive.
UDM 50110C:Exchange with Taiwan milling head ,motorized lifting and lowering of table Z axis
| Model | UDM 50110 | UDM 50110A | UDM 50110B |
| Max.drilling dia.(MT4 taper)(mm) | 50 | 50 | 50 |
| Max.end milling width(mm) | 100 | 14(cast iron) | 100 |
| Max.vertical milling dia.(mm) | 25 | / | 25 |
| Max.tapping dia. | M16 | 25 | M16 |
| Distance from spindle nose to table surface(mm) | 90-400 | 100-430 | 100-460 |
| Spindle speed range(r.p.m) | 110-1760(V) 38-1310(H) | 90-2000(V) 38-1310(H) | 115-1750(V) 38-1310(H) |
| Spindle travel(mm) | 120 | 120 | 120 |
| Table size(mm) | 1120×280 | 1120X260 | 1120×260 |
| Table travel(mm) | 600×230 | 600X300 | 600×270 |
| Overall dimensions(mm) | 1580×1330×2250 | 1520X1285X2150 | 1655×1450×2150 |
| Main motor power(kw) | 0.85/1.5(V) 2.2(H) | 2.2 | 0.85/1.5(V) 2.2(H) |
| N.W/G.W(kg) | 1350/1500 | 1350/1500 | 1500/1600 |
| Item No. | 141020 | 141021 | 141022 |
| Standard accessories | Optional accessories: | |
| Drill chuck | Dividing head F11100A | |
| Inner-haxagonal spanner | Rotary table TS250A | |
| Wedge shifter | Halogen work lamp | |
| Reduction sleeve | Digital Readout | |
| Draw bar | Clamping Kits | |
| Spindle Abor | Power Feed | |
| wrench | Cooling System | |
| Machine vice | ||
| Milling chuck | ||
| Horizontal milling abor | ||
| Operation manual | ||
| Quality certificate | ||
| Packing list | ||
