Home > Products > toggling machine > 1800mm work size 30m length goat or sheep leather auto toggling machine
1800mm work size 30m length goat or sheep leather auto toggling machine
- 100 Set / Sets per Month
- Shanghai port
- T/T Credit Card
-
Automatic Ultrasonic Zipper Pulling Tacking New
-
Automatic zipper point cutting bundling machine(Dual Strip）
-
Fully automatic ultrasonic trim dot printing and binding machine
-
Automatic zipper point cutting bundling machine
-
Automatic Ultrasonic Zipper Pulling Tacking
-
Automatic ultrasonic folding ring bonding machine
Product Details
| Condition: | New | Automatic Grade: | Automatic | Place of Origin: | Jiangsu, China |
| Brand Name: | DUNCHENG | Model Number: | DCH | Type: | Other, leather auto toggling machine |
| Voltage: | 380v/3phase | Power(W): | up to machine | Dimension(L*W*H): | up to machine |
| Weight: | up to machine | Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
leather auto toggling machine1.chain slat driver type
2.low consume
3.auto count and finalize the design
leather auto toggling machine key point
1.PLC control
ntinues running
3.two radiator
4.galvanize steel
5.dry energy : steam,electric,hot oil , natural gas and so on
6.for sheep goat cow and so on
leather auto toggling machine Specification
Auto toggling machine information | ||||||||
Model | Work size (m) | Stretching size (mm) | Capacity (PCS) | heat producer (Mpa) | Dryer temperature (degree) | Speed (m/min) | Power (kw) | Weight (Kg) |
DCH3-160 | 1.6 | 0-120 | 60-220 | 0.3 steam | 20-70 | 16.5 | 12.55 | 12970 |
DCH3-180 | 1.8 | 13.55 | 13500 | |||||
DCH3-200 | 2.0 | 14.55 | 14000 | |||||
DCH3-220 | 2.2 | 14.55 | 14700 | |||||
leather auto toggling machine key parts
leather auto toggling machine buyer
France ,Indonesia ,Pakistan , India ,Mongolia ,Malaysia and so on
Spare parts supply
Item | Name | Q’ty | Code in circuit diagram | remark |
1 | Sheet of chain | 30 pcs | ||
2 | PLC | 1PC | ||
3 | Text display | 1pc | ||
4 | Small relay | 4pcs | KOO | |
5 | fuse | 2pcs | Q | |
6 | contactor | 2pcs | KO | |
7 | Temperature meter | 2pcs | SWK |
