leather process machine of staking machine for tannery
- 100 Set / Sets per Month
- Shanghai
- T/T
You May Like
-
leather process machine 1600 to 3200mm 2 or 3 or 4 head
-
staking machine for machines tannery for sale
-
sheep goat cow crust skin machine leather staking machine 1600 to 3200mm leather vibration staking machine
-
tannery machine of vibration staking machine exporter
-
China tannery machine of vibration staking machine
-
Italy quality tannery machine 1600 to 3200mm leather vibration staking machine
Product Details
| Condition | New | Automatic Grade | Automatic | |
| Place of Origin | Jiangsu, China | Brand Name | DCH | |
| Model Number | DCHZL | Type | Other, staking machine for tannery | |
| Voltage | 380v/3phase | Power(W) | up to machine | |
| Dimension(L*W*H) | up to machine | Weight | up to machine | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
staking machine for tannery1.auto remove crease
2.auto dusty collect
3.auto oil lubration
staking machine for tannery key point
1.Auto lubricating system
2. Auto remove crease unit
3. Auto air dusty collector
4. PLC control all system
staking machine for tannery Specification
Size and head | Work width | Vibration frequency | Feeding speed | Total power | Working pressure | Machine size | Weight |
1600-4 head | 1600mm | 600t/m | 0-20m/min | 22kw | 3.5-4.5mpa | 2220x2970x1610 | 11000kg |
2400-4 head | 2400mm | 600t/m | 0-20m/min | 29.7kw | 4.5-5.5mpa | 3020x2970x1610 | 15000kg |
3200-4 head | 3200mm | 600t/m | 0-20m/min | 29.7kw | 4.5-5.5mpa | 3820x2970x1610 | 18000kg |
Size and head | Work width | Vibration frequency | Feeding speed | Total power | Working pressure | Machine size | Weight |
1600-3 head | 1600mm | 600t/m | 0-20m/min | 23.4kw | 3.5-4.5mpa | 2220x2970x1610 | 9000kg |
2400-3 head | 2400mm | 600t/m | 0-20m/min | 30.4kw | 4.5-5.5mpa | 3020x2970x1610 | 11000kg |
3200-3 head | 3200mm | 600t/m | 0-20m/min | 38.4kw | 4.5-5.5mpa | 3820x2970x1610 | 14000kg |
Size and head | Work width | Vibration frequency | Feeding speed | Total power | Working pressure | Machine size | Weight |
1600-2 head | 1600mm | 600t/m | 0-20m/min | 9kw | 3.5-4.5mpa | 2220x2970x1610 | 6500kg |
2400-2 head | 2400mm | 600t/m | 0-20m/min | 12.5kw | 4.5-5.5mpa | 3020x2970x1610 | 7500kg |
3200-2 head | 3200mm | 600t/m | 0-20m/min | 17.2kw | 4.5-5.5mpa | 3820x2970x1610 | 9000kg |
staking machine for tannery part brand
No | Part | Brand list |
1 | BEARING | JAPAN |
2 | Hydraulic pump | JAPAN |
3 | Breaker | JAPAN OR FRANCE |
4 | Contactors | JAPAN OR FRANCE |
thermal relay | JAPAN OR FRANCE | |
air base | GERMANY | |
cloth | ITALY | |
valve | JAPAN |
