three model Tannery fleshing hydraulic leather fleshing machine
- 100 Set / Sets per Month
- Shanghai
- T/T
- Automatic Ultrasonic Zipper Pulling Tacking New
- Automatic zipper point cutting bundling machine(Dual Strip)
- Fully automatic ultrasonic trim dot printing and binding machine
- Automatic zipper point cutting bundling machine
- Automatic Ultrasonic Zipper Pulling Tacking
- Automatic ultrasonic folding ring bonding machine
Product Details
Condition: | New | Automatic Grade: | Automatic | Place of Origin: | Jiangsu, China |
Brand Name: | DCH | Model Number: | fleshing hydraulic leather fleshing machine | Type: | Other, fleshing hydraulic leather fleshing machine |
Voltage: | 3 phase 380v,60Hz | Power(W): | 55 | Dimension(L*W*H): | 5600x2800x2000mm |
Weight: | 3500kg | Certification: | CE | Warranty: | one year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
fleshing hydraulic leather fleshing machine1.Italy blade,feed,drive and line roller
2.hydrualic or machinery flesh
fleshing hydraulic leather fleshing machine key point :
1.hydraulic system fleshing machine
2.stainless steel machinery structure
3.special for cow cattle buffalo and so on
4.one system for control two sets machine running together
5.auto balance unit Rubber rod pallet for keep difference thickness skin get good finally quality
6. rhombic channel roller ensure skin never move during running
7.double times auto protect system
9.auto grinder for blade
fleshing hydraulic leather fleshing machine pecification :
Working width (mm) | 2200 | 2700 | 3200 |
O/D of blade cylinder | 260 | 260 | 260 |
Speed of blade cylinder | 1480 | 1480 | 1480 |
Main motor (KW) | 45 | 45 | 55 |
Pump pressure (bar) | 40-45 | 40-45 | 40-45 |
Feed speed (m/min) | 19-50 | 19-50 | 19-50 |
Oil pump motor (Kw) | 11 | 11 | 15 |
Capacity(pc/h) | 120-150 | 120-150 | 120-150 |
Outline (LxWxH) (mm) | 4400x1540x1600 | 4900x1540x1600 | 5400x1540x1600 |
Net weight (KG) | 7200 | 7850 | 9000 |
fleshing hydraulic leather fleshing machine warrantee time :
one year after machinery arrive in buyer factory ,during one year ,if machinery part damage except by person, factory free change ,but transport charge paid by buyer
fleshing hydraulic leather fleshing machine installation :
free install within one week ,but visa charge, tickets go and back, hotel and food will be arranged by buyer.
