24v 400hz electroless 100 amp rectifier
We are professional and creative manufacturer. Our reliable quality of rectifiers will definitely satisfy your requirements.
Advantage:
1) Small, light and high efficiency
2) High frequency pulse current output
3) Flexible use, simple operation
4) Complete protection function
| Model | Description | Parameter | Application |
| DR-6000A-12V |
1.Compact volume , light weight , high efficiency, high accuracy of controlling; 2.Advanced technology: Bridge Rectifier Modules are adopted as main power devices and ultracrystallite soft magnetism materials are adopted as magnet core of main transformer. 3.Reliable protective functions against lack of phase, over current, over heat and etc. High efficiency, low pollution and no interference to electricity power net. 4.The output voltage and current are adjustable, widening the range of application. 5.Special structure for antisepsis to increase the service life under harsh environment. |
1.Output voltage:0-12v 2.Ourput current:0-6000A Note: we could customized in accordance with customers requirements 3.Input voltage range 3-phase AC380V±15 50HZ 4.Range of output Conditioning:At 0 to100 of rated voltages,At 0 to100 of rated currents 5.Adjustmentrange:From 0-100 continuously adjustable 6.Output conditioning method: Switching mode 7.Machine efficiency:≥85% 8.Range of output Conditioning:At 0 to100 of rated voltages and currents 9.Constant voltage control accuracy:Within 1.0of rated output voltage 10.Constant current control accuracy:Within 1.0of rated output current 11.Insulation resistance:5M or more 12.Cooling system:Forced aie cooling 13.Workingcondition:a.Loction:Indoors b.Ambient temperatuer:-20-40 c.Relative:30-85 14.Altitude:2500 more or less |
1. All units guaranteed 24 months from supply against failure, bad workmanship and material defects excluding misuse of operational conditions.
2. Strong technical ability ensures reasonable, professional and safe design.
3. Good quality components are used.
4. Full load testing before shipment.
5. Complete protections.
6. Meet CE requirement.
1) Surface treatment: Electroplating. Electrolytic metal treatment. Metal finishing. Base metals. Non metals and plastics. Barrel plating. Rack plating. Continuous plating. Hard aluminum anodizing. Decorative anodizing.
2) Electrolysis: All major applications. Metal electrowinning. Electrorefining. Sodium hydroxide electrolysis. Salt electrolysis. Sodium chloride electrolysis. Chlor alkali electrolysis. Water electrolysis.
3) Cathodic protection water purification. Water electrocoagulation and inductive heating.
Please view more products on our website: http://www.dorik.en.china.cn
