2m ultrasonic fog screen machine
- 200 Set / Sets per Month
- Ningbo
- T/T Credit Card
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | Dorik | Model Number: | DR-3kw |
Product Description
2m ultrasonic fog screen machine
1. introduction
Fog screen system use electronic overclocking, through the high frequency resonant transducer, will produce the natural flowing water by making the water leave water spray, without heat or chemicals to produce 1-10μ particles floating in the air. Then based on the principle of air flow, it produces a fog screen which is formed by a plane of fog.
2.Technical parameter
Product name | 2m fog screen downward spray effect machine |
Spray type | downward spray |
Screen area | 2*1.5-3m(the volume and height of fog depend on the surroundings) |
Play imaging equipment | projector or laser |
Power supply | AC220V |
Power | 3 KW |
Water consumption | 10~15L/H(It can work for 1.5H if reserved water tank is full ) |
Size of fog screen generator | 2.05*0.4*0.5m |
Size of electric cabinet | 0.5*0.3*0.55m |
Size of reserved water tank | 0.5*0.3*0.55m |
Weight of reserved water tank | 15KG |
Net weight of electric cabinet | 45KG |
Net weight of generator | 100KG |
Projector required | above 5000lumen(there shouldn't have any references in front of projector) |
3. Advantage
Compared with traditional projector screen
1)The fog screen is used as an optical carrier, and then smooth media fluid is projected on it, thus forming a three bit stereo image, providing us a new stereo visual enjoyment. People can freely shuttle in the empty phantom image. It feels like real people can step into the video screen. Due to the unique characteristic that can be illusory image, the fog screen effect machine has a broad market prospect.
2)No mechanical drive, quiet and noiseless, high atomizing efficiency, low failure rate, easy maintenance.
3)Box body is made of full stainless steel spray, beautiful appearance, practicality, and equipped with a standard water inlet, water drain switch and overflow, water level automatic control etc.
4)Raw material: Ordinary tap water, environmental protection and energy saving.
5)Each fog screen unit can be used alone, can also be used in combination to form various shapes
6)Fog screen device can project computer program, infrared, laser, radar through the projector light onto the screen by the wind fog, forming a variety of dynamic, virtual image.
7)Fog mist is non-toxic, tasteless, environmental friendly and produces negative ions. Visitors can enjoy the interaction with the fog screen.
8)The fog will not stay in the room, once power off, completely gasification.
9)Installation requirements of the site is not strict, can be installed in the hall, corridor, elevator door etc.
10)There are two kinds of installation way: hanging equipment and floor type, not only for the
convenience of the installation of equipment, but also improve the efficiency in the use of space
11) Equipment design is through repeated experiments and years of actual testing, compact structure, reasonable collocation, no large power motor, and no noise at work.
4. Application
It can be a new display media applied in stage theater,media exhibitions,shopping malls, disco, KTV, tourist attractions, theme parks, entertainment, science and technology museum, museum, museum of planning, new product launches, performing arts venues, children's Museum of Science Park and so on.
5. After service
1. If components are broken within guarantee period due to power supply design or component bad quality, supply replacement free.
2. For overseas customers, in case of problems with power supply, respond within 24 hours from receiving customer's written inform.
3. Supply detailed operation manual and troubleshooting table .
4. Supply technical support to find out problem reason and guidance of troubleshooting.
