AC/DC 24 volt 300W switch power supply
Features:
- Switching Power Supply
- AC input range selectabel by switch
- 100% full load burn-in test
- High efficiency, long life and high reliable
- 2 years warranty
Model | D-300-24 | ||||
Output | DC voltage | 24V | |||
Voltage tolerance | ±1% | ||||
Rated current | 12.5A | ||||
Current range | 0~12.5A | ||||
Rated power | 300W | ||||
DC voltage adjustable range | ±10% | ||||
Input | Voltage range | 90 ~ 132VAC / 180 ~ 264VAC | |||
Frequency | 47~63HZ | ||||
Efficiency | 78% | ||||
Protection | Over load | 105 ~ 135% rated output power | |||
Protection type: Hiccup mode, auto-recovery after fault condition is removed. | |||||
Over voltage | Protection type: Hiccup mode, auto-recovery after fault condition is removed. | ||||
Environment | Working temp,humidity | -10°C~+60°C, 20%~90%RH | |||
Storage temp,humidity | -20°C~+85°C, 10%~95%RH non-condensing | ||||
Withstand vibration | 10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes | ||||
Safety | Withstand voltage | I/P-O/P:1.5KVAC, I/P-FG:1.5KVAC, O/P-FG:0.5KVAC | |||
Isolation resistance | I/P-O/P, I/P-FG, O/P-FG: 100M ohms/500VDC | ||||
Fit standard | Safety standard | Compliance to UL1012 | |||
EMC standard | Compliance to EN55022,CLASS A | ||||
Others | Dimension | 215*115*50mm(L*W*H) | |||
Weight | 0.95kg | ||||
1. If components are broken within guarantee period due to power supply design or component bad quality, supply replacement free.
2. For overseas customers, in case of problems with power supply, respond within 24 hours from receiving customer's written inform.
3. Supply detailed operation manual and troubleshooting table .
4. Supply technical support to find out problem reason and guidance of troubleshooting.
