Home > Manufacturing & Processing Machinery > Cutting & Fold-bend Machine > Bending Machine > 1500W 3'' Hydraulic and Pipe Threading Machine SQ80C1
US$ 800 - 808
MOQ: 5 Sets
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
HAOBAO
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hotsale and Hydraulic and Pipe Threader SQ-50DUS$ 800 - 900MOQ: 1 Set -
High Quality and Pipe Threading Machine SQ-100FUS$ 360 - 400MOQ: 10 Sets
-
1500W 4'' Electric Pipe Threading Machine SQ-100FUS$ 500 - 590MOQ: 10 Sets
-
12'' Hydraulic Roll Groover YG12AUS$ 1,200 - 1,300MOQ: 1 Set
-
1500W 12'' Tube Roll Groover YG12AUS$ 1,000 - 1,109MOQ: 1 Set
Condition
New
Place of Origin
Zhejiang, China
Brand Name
HAOBAO
Model Number
SQ80C1
Machine Type
Other, threading machine
Raw Material
Pipe
Material / Metal Processed
Stainless Steel
Power
Hydraulic
Automation
Automatic
Extra Services
Cut To Length
Certification
ISO 9001:2000
After-sales Service Provided
Overseas third-party support available
Specifications
3'' Threading Machine SQ80C1Equipping with 2 automatic die head
The copy of RIDGID1233
Hydraulic and Pipe Threading Machine SQ80C1
Featuring
Compact and durable design with powerful universal motor,net weight only 74kg.
All sizes of threads get processed only in one turn.
The most light-weight 3" threader
Specifications
Motor: 1500W universal type, 110V or 220V, 50-60Hz
Spindle Speed: 32 RPM
Net Weight: 74KG
Capacity:1/2"-3" (BSPT & NPT) (1/2"-3/4", 1"-2", 2 1/2"-3" ) for threading
Equipping 2 automatic die heads, trigger off automatically while threads length meets
Adjustable oiling flow; Through the head, with an integral oil reservoir
Self-priming, constant-flow geroter pump
Ordering information
| Cat no . | Model no. | Description | Weight |
| 47020 | SQ80C1 | complete set 1/2"-3",220V-50HZ,BSPT | 74KG |
| 47010 | SQ80C1 | complete set 1/2"-3",110V-60HZ,NPT | 74KG |
Accessories
| Cat no. | Model no. | Description | Weight |
| Die head,1/2"-2",Automatic | 6KG | ||
| Die head,1/2"-3",Automatic | 7.5KG | ||
| Nipple chuck,BSPT | 4.8KG | ||
| Nipple chuck,NPT | 4.8KG |
Dies set
| Cat no. | Size | Material | Weight |
| 1/4"-3/8" BSPT(optional) | HSS | 0.75KG | |
| 24051 | 1/2"-3/4" BSPT | HSS | 0.75KG |
| 24053 | 1"-2" BSPT | HSS | 0.75KG |
| 1/4"-3/8" NPT(optional) | HSS | 0.75KG | |
| 21051 | 1/2"-3/4" NPT | HSS | 0.75KG |
| 21053 | 1"-2" NPT | HSS | 0.75KG |
| 24053 | 1"-2"BSPT | HSS | 0.75KG |
| 24504 | 2 1/2"-3"BSPT | HSS | 0.7KG |
| 21054 | 2 1/2"-3"NPT | HSS | 0.7KG |
