2015 Hot sale,good supplier Electro-magnetic Induction heater for bearings,bearing heater machine
- 850 Piece / Pieces per Month
- Qingdao/Shanghai
- T/T Credit Card
- Heater Core Heater Welding Gun Heater Element
- Industrial Diesel Heater /Agricultural Vegetable Planting/Aquaculture Industry Heater
- Preheating equipment for hardbandig welding
- Heater Core Heater Welding Gun Heater Element
- DL-3 model electric air heater with upper outlet and lower inlet
- DL-2 model electric air heater with Left-Right Circulation
Product Details
Condition: | New | Type: | Duct Heater | Power Source: | Electric |
Place of Origin: | Shandong, China | Brand Name: | QK | Model Number: | TIH |
Dimension(L*W*H): | 260*240*260 | Weight: | 15kg | Voltage: | 220 or 380, 12v/24v/48/110v/120v/220v/240v/380v/420v |
Power(W): | 3.5kw | Certification: | ISO9001 | Warranty: | 1 year |
After-sales Service Provided: | No overseas service provided |
Product Description
2015 Hot sale,good supplier Electro-magnetic Induction heater for bearings,bearing heater machine
Description:
- Improve assembly quality, even heating, high precision, keep surface harness constant;
- Improve work efficiency, quick heating speed, reduce works strength, improve assembly progress, reach to the aim of civilized production;
- Rational and advanced in structure, easy, safe, reliable to operate with fire danger;
- Save energy sources, reduce cost, improve profit, saving 100% oil compared with oil induction heating, save 60% oil compared with electric furnace;
- After stopping heating, ZJ series induction heater will automatically demagnetize below 0.8mt, which conforms to ZJS-004 standard. So it is the best induction heater equipment for civilized production, high-efficiency production and safe production.
Parameter For Induction Bearing Heater:
TechnicaI data
performance 97 kg (213 lb)
Voltage, V/Hz 230V/50-60Hz or 400-460V/50-60Hz
Work piece:
– Maximum weight 120 kg (264 lb)
– Maximum bore diameter 20 – 400 mm (0,8 – 15,7 in)
Temperature control:
– Range 0 – 250 °C (32 – 482 °F)
– Magnetic probe Yes, K–type
– Accuracy (electronics) ± 2 °C (± 3,6 °F)
Time control:
– Range 0 – 60 minutes
– Accuracy ± 0,01 sec.
Maximum temperature (approx.) 400 °C (750 °F)
Thermometer mode Yes
Bearing mode Yes
Power reduction 2–step; 50 – 100%
Demagnetisation according to SKF norms (automatic) Yes (<2 A/cm)
Can heat sealed bearings Yes
Can heat pre – greased bearings Yes
Error guiding codes Yes
Thermal overload protection Yes
Maximum magnetic flux 1,7 T
Control panel Key board with LED in remote control
Operating area (w × h) 155 × 205 mm (6,1 × 8,0 in)
Coil diameter 110 mm (4,3 in)
Dimensions (w × d × h) 570 × 230 × 350 mm (22,4 × 9,0 × 13,7 in)
Total weight, including yokes 42 kg (92 lb)
Maximum power consumption 3,6 kVA (230V)
4,0-4,6 kVA (400-460V)
Number of standard yokes 3
Standard yokes 56 × 56 × 296 mm (2,2 × 2,2 × 11,7 in), for heating bearings with
bore diameter of 80 mm (3,1 in) and larger
28 × 28 × 296 mm (1,1 × 1,1 × 11,7 in),for heating bearings with
bore diameter of 40 mm (1,6 in) and larger
14 × 14 × 296 mm (0,6 × 0,6 × 11,7 in), for heating bearings with
bore diameter of 20 mm (0,8 in) and larger
Core cross section 56 × 56 mm (2,2 × 2,2 in)
Yoke storage Yes, foldable
Sliding arm No
Swivel arm Yes, large yoke only
Cooling fan No
Housing material Steel and glass filled polyamide
Delivery time for order within available stock is in 7days
Delivery time for order without available stock is in 15days
Pre-sale Service
1.Supply item design,process design.
2.Help you to chose the fit machine.
3.Making the machine according to your requirement.
Sale Service
1.Acceptance equipment together with you.
2.Help you to make the method statement and the details of the process.
After Service
1.Guarantee for a year.
2.Quality problem,we will send you the accessories.
3.Free repair whole using life(without the freight and accessories charge).
Jining Qingke Machinery Co., LTD. established in July 29, 2015, registered capital
of 5.6 million . We have 4 branch companies in Jining ,Linyi and Qingdao
Main products: Garden Machinery including tree spade , lawn mower, Skid Loader, Mini
Excavator,Construction machinery and accessories, Road Marking and Mining equipment,
Mining tools and so on. In July 2006 we passed the ISO9001:2000 certification.
Our company products have been exported to the United States, Britain, France, Japan,
Italy and more than 20 countries.
Are you manufacture?
Yes. We are one of leading manufacturers for Kinds of pneumatic torque wrench with many
new production line.
Do you have Stock producions to sell?
Yes, of course. But we also offer OEM service. Please send us some drawing.
What information do you want to know if i want to get a quotation?
a). The model/size of your products.
b). The application fo your products.
c). Special package methods if you needs.
d). Raw material.
Do you inspect the finished products?
Yes. Each step of products will be carried out inspection by QC department until shipping.
What advantages do you have?
(a).Punctual: Have your orders met with the latest delivery?
We are a manufacturer with so many advanced and new machines.
It ensures we have the ability to carry out the production schedual for punctual delivery.
(b).20-year production experience. We have over 20 years exprerience in this industry.
That means we can preview the problems for the orders and production.
Therefore, it will make sure to deduce the risk of bad situation to happen.
(c). Point to point service.
There is two sales departments who will serve you from inquiry to products shipped out. During the
process, you just need to discuss with him for all the problems and the way sames much times.
