Home > Products > induction bearing heater > HA Serious Self-demagnetic Induction Bearing Heating Tools Eddy Current Heater
HA Serious Self-demagnetic Induction Bearing Heating Tools Eddy Current Heater
- Qingdao/Shanghai
- T/T Credit Card
You May Like
-
HA Serious Self-demagnetic Induction Bearing Eddy Current Heater
-
Large Heating Temperature Range Diameter 15mm to 200mm 1KVA Induction Bearing Heater
-
TIH100M Induction Heater for Bearings, Shaft Heat Treatment Tools
-
TIH100M Induction Heating Machine Equipment Tools
-
TIH100M Induction Bearing Heater for Extruder Digital Temperature Control System
-
Skf Induction Sleeve Bearing Heater Heating Equipment
Product Details
| Condition | New | Type | Duct Heater | |
| Power Source | Electric | Place of Origin | Shandong, China | |
| Brand Name | QK | Model Number | TIH | |
| Dimension(L*W*H) | 260*240*260 | Weight | 15kg | |
| Voltage | 220 or 380, 12v/24v/48/110v/120v/220v/240v/380v/420v | Power(W) | 3.5kw | |
| Certification | ISO9001 | Warranty | 1 year | |
| After-sales Service Provided | No overseas service provided |
Product Description
HA Serious self-demagnetic Induction bearing heating tools eddy current heater
Description:
- Improve assembly quality, even heating, high precision, keep surface harness constant;
- Improve work efficiency, quick heating speed, reduce works strength, improve assembly progress, reach to the aim of civilized production;
- Rational and advanced in structure, easy, safe, reliable to operate with fire danger;
- Save energy sources, reduce cost, improve profit, saving 100% oil compared with oil induction heating, save 60% oil compared with electric furnace;
- After stopping heating, ZJ series induction heater will automatically demagnetize below 0.8mt, which conforms to ZJS-004 standard. So it is the best induction heater equipment for civilized production, high-efficiency production and safe production.
TechnicaI data
Model | SMBG-2.0 | SMBG-3.6 |
Power(KVA) | 2.0 | 3.6 |
Voltage(V) | 110/220V | 110/220V |
pillar dimension(mm) | 40×40 | 60×60 |
Pillar Height(mm) | 110 | 150 |
Inner diameter of bearing(mm) | φ > 15 | φ > 30 |
Outer diameter of bearing (mm) | 400 | 500 |
Maxi Width of bearing(mm) | 145 | 140 |
Maxi bearing Weight (KG) Other parts | 20 15 | 30 20 |
Temperature control (digital reveals) | 50-240℃ | 50-240℃ |
Time control (digital reveals) | 99minute 59second | 99minute 59second |
acoustical signal | yes | yes |
The error operation | (digital reveals) | (digital reveals |
Temperature Kept | YES | YES |
self-demagnetization | YES | YES |
Dimension(cm) | 32×32×25 | 32×32×32 |
Heating bar Height Standard configuration(mm) | 10,24,40 | 20,30,40,60 |
rotary apparatus | No | No |
Delivery time for order within available stock is in 3 days
Delivery time for order without available stock is in 5 days
Pre-sale Service
1.Supply item design,process design.
2.Help you to chose the fit machine.
3.Making the machine according to your requirement.
Sale Service
1.Acceptance equipment together with you.
2.Help you to make the method statement and the details of the process.
After Service
1.Guarantee for a year.
2.Quality problem,we will send you the accessories.
3.Free repair whole using life(without the freight and accessories charge).
