SKF Heavy Duty Bearing Heater for Mining Equipment and Oil Equipment
- Qingdao
- T/T Credit Card
You May Like
-
3.6KVA Induction Heater for Bearing/gear/sleeves Assembly
-
SMBG Induction Heater For Bearings Mount And Dismount
-
Induction Gear Ring Puller Induction Bolt Heating Machine
-
Lightweight Design TIH 220m Portable Bearing Induction Heater
-
Installation Tools Portable Induction Magnetic Bearing Heater Use for Assemble and Disassemble
-
ELDC Portable Serious Intelligent Bearing Heater
Product Details
| Condition | New | Type | Other, induction heater | |
| Power Source | Electric | Place of Origin | Shandong, China | |
| Brand Name | QK | Model Number | SMBG | |
| Dimension(L*W*H) | 32*32*25cm | Weight | 28kg | |
| Voltage | 220-380V | Power(W) | 2.0kw | |
| Certification | ISO9001:2008 | Warranty | 2 Years | |
| After-sales Service Provided | No overseas service provided |
Product Description
SKF Heavy Duty bearing heater for Mining equipment and Oil Equipment
Model | SMBG-2.0 | SMBG-3.6 |
Power(KVA) | 2.0 | 3.6 |
Voltage(V) | 110/220V | 110/220V |
pillar dimension(mm) | 40×40 | 60×60 |
Pillar Height(mm) | 110 | 150 |
Inner diameter of bearing(mm) | φ > 15 | φ > 30 |
Outer diameter of bearing (mm) | 400 | 500 |
Maxi Width of bearing(mm) | 145 | 140 |
Maxi bearing Weight (KG) Other parts | 20 15 | 30 20 |
Temperature control (digital reveals) | 50-240℃ | 50-240℃ |
Time control (digital reveals) | 99minute 59second | 99minute 59second |
acoustical signal | yes | yes |
The error operation | (digital reveals) | (digital reveals |
Temperature Kept | YES | YES |
self-demagnetization | YES | YES |
Dimension(cm) | 32×32×25 | 32×32×32 |
Heating bar Height Standard configuration(mm) | 10,24,40 | 20,30,40,60 |
rotary apparatus | No | No |
Induction bearing heater, mainly used in metallurgy, railway, oil field, mechanical, electrical and other a lot of enterprises manufacturing and maintenance machinery in the process need to be sleeved bearings, couplings, gears, bushings and other annular shaped hole part induction heating.
Induction bearing heater by electromagnetic induction principle, will be thermally processed workpiece for secondary coil, when electricity is heating the workpiece under the action of electromagnetic induction current, from the inside and surface generated thermal expansion, which meet the needs of fit.
