Alloy saw blade grinding machine
Related products
Product Feature
- All cast iron is made of nodular graphite cast iron (FCD-45) in order to ensure the accuracy and increase the wear resistance.
- All the adjusting rods are carefully arranged so that the cutting angle can be easily adjusted, the back gap angle, the tooth depth and the pitch angle can be easily and quickly and accurately
- Use variable belt pulley,Can be changed with the change of pitch to adjust the required speed.
- The grinding wheel head can swing up and down,So can not replace the grinding wheel, can be easily grinded chamfer
- Saw blade thickness variation,Can be easily adjusted,And there is a scale can be directly seen in the thickness of the tune
- The driving part is driven by the grinding wheel motor and the structure.,In order to achieve the true, safe transmission
- The end of the feed claw has a super hard tungsten carbide,The wear and tear of the feed claw can be reduced to the lowest, and the accurate feed can be achieved..
Attention
- This machine is mainly for grinding high speed steel circular saw blade
- May be repaired with 50~480mm diameter, 8mm thick circular saw blade milling cutter
- Material is not limited, can be based on your actual blade material to buy grinding wheel
- Grinding wheel according to national standards, the market can buy
- If your blade diameter is less than 50mm, you can customize the fixture with me, the model unchanged
Specification
Outer saw diameter |
Φ50-450mm |
Speed of grinding wheel |
4200rpm |
OD of grinding wheel |
Φ70-150mm |
Cutting angle |
0°-30° |
Saw depth of notch |
8mm |
Saw max pitch |
25mm |
Feed Speed |
45-180teeth/min |
Drive motor |
1/2HP |
Net weight |
130kg |
Package size |
130x80x80cm |
Detail
Shippment
Company Information
Jining Qingke Machinery Co., Ltd established in July 29, 2015, registered capital of 5 million.
This is our new branch. Our factory has 6 years history. We have CNC machining center, CNC
lathe, boring machine, and milling machine.
Main products: edge grinder, Steel bar cutting machines, Bending machines, Straightening machines, Steel arc bending machine, Ground polishing machines, Terrazzo machines, Solar water pump, Garden Machinery(including tree spade & lawn mower), Construction machinery and accessories, Road marking and Mining equipment, Mining tools and so on.
We have passed the ISO9001:2000 certification. Our products have been exported to Europe, Russia, south America, Africa & the Middle East, more than 20 countries. We sincerely hope to have the opportunity to co-operate with you.
