orchard Chain Ditcher banking machine
Related Products
Description
This product is made according to the customer need to design, specifically for the 15 - 95 horsepower tractor supporting the use of novel ditching equipment. It is in common tractors by installation of super low speed transmission device to realize low speed slow, so that the ditch deep under the unified, about the width of symmetry.
This machine adopts rotary furrower,Furrow width is 10 - 40 cm,Ditching depth adjustable,The maximum digging depth of 160 cm,Ditching the speed up to 50 per hour - 500 meters.The ditch ditch straight, steep cliffs, deep ditch and gully width uniform, and artificial excavator can not open this ditch shape.Mainly applicable to underground pipeline irrigation of farmland water conservancy, tap water pipe and cable laying underground ditching work.
Ditching maneuvering force types of 15-95 horsepower four-wheel tractor and applicable in the field of forestry and farming wide 15,20,25,40,60cm,100 - 500m/h, this deep 0-160cm productivity farming.
Detail
Specification
Model | 900/200 | 1200/300 |
Digging width | 200mm | 300 mm |
Digging depth | 900mm | 1200 mm |
working pressure | 16 MPa | 16 MPa |
Work flow | 50-75 L/min | 50-75 L/min |
Weight | 320 Kg | 530 Kg |
Length | 1950 mm | 3300 mm |
Width | 1160 mm | 1265 mm |
Height | 850 mm | 900 mm |
Applicable motorcycle models | 1.8t/3t/5t | 3t/5t |
Jining Qingke Machinery Co., Ltd established in July 29, 2015, registered capital of 5 million. This is our new branch. Our factory has 6 years history. We have CNC machining center, CNC lathe, boring machine, and milling machine.
Main products: Chain Ditcher , Steel bar cutting machines, Bending machines, Straightening machines, Steel arc bending machine, Ground polishing machines, Terrazzo machines, Solar water pump, Garden Machinery(including tree spade & lawn mower), Construction machinery and accessories, Road marking and Mining equipment, Mining tools and so on.
We have passed the ISO9001:2000 certification. Our products have been exported to Europe, Russia, south America, Africa & the Middle East, more than 20 countries. We sincerely hope to have the opportunity to co-operate with you.
If you have any questions, please don't hesitate to contact me:
Linda Liu
Jining Qingke Machinery Co.,Ltd
Tel/whatsApp/Wechat: +8615650379513
Email: doingmachine(at)
Skype: qkmachinery
QQ: 2033085688
