Specifications
Honda engine GX210 (7HP)4-Stroke
Single-cylinder
Air-cooled Direct injection
GASOLINE ENGINE
WE CAN SUPPLY ALL KINDS OF GASOLINE ENGINE.
Honda engine GX210
FEATURE OF PRODUCTS
1) Adopt 4-Stoke OHV gasoline engine;
2)Close in structure, simple in operation and covenievent in takeing or bringing;
3)Having Ideal air burning rate so as to make waste air discharge more perfectly;
4)Widely use in park and garden constructions, carrying water on high place, farm field ploughing and weeding, generator units ect. For which the moving powers are matched.
MODEL: YL170F
Engine Type: Forced air-cooled, one cylinder, four stroke, OHV
Displacement: 215CC
Bore x Stroke: 70x56
Compression Ratio: 8.5: 1
Rated Output: 7/4Kw/3000rpm
Max Output: 7.5Hp/4.2Kw/3600rpm
Rated Torque: 10.8N. M/2500rpm
Lubrication system: Splash
Start Model: Recoil and hand-operated
Ignition Model: Transistorized magneto ignition
Air Cleaner Model: Semi-dry, oil bath, dual element
Fuel Tank Capacity: 3.6L
Oil Tank Capacity: 0.6L
N. W: 15KG
G. W: 16.5KW
Packing Size: 400x350x385mm
20GP/40GP: 405sets/912sets
Honda engine drawing
