Home > Industrial Equipment & Components > Engine & Part > Engine > Air-cooled Kama Diesel Engine,small Diesel Engine (12HP)
Air-cooled Kama Diesel Engine,small Diesel Engine (12HP)
Negotiable
MOQ: 20 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Usage:
Other, water pump
Fuel:
Diesel
Stroke:
4 Stroke
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Usage
Other, water pump
Fuel
Diesel
Stroke
4 Stroke
Cylinder
Single Cylinder
Cold Style
Other, Air-cooled
Start
Kick Start
Place of Origin
Zhejiang, China
Brand Name
YOLEE
Model Number
YL186F
Specifications
kama Diesel Engine Modle: 188F(12HP)Strong Power, Fast Actuate
Light Weight, High Quality
Low Fuel, Low Vibration
| Model | 188F (12hP) |
| Cooling method | Air-cooled |
| Type | Single cylinder, Vertical, Fourstroke, Direct injection |
| Bore× Stroke(mm) | 88*75 |
| Displacement(ML) | 456 |
| Compression ratio | 19: 1 |
| Engine Speed | 3000/3600 |
| Rated power(kw/rpm) | 6.8/3000 |
| Max Power(kw/rpm) | 7.6/3000 |
| Fuel | 0#or-10# light diesel oil |
| Fuel tank capacity(L) | 5.5 |
| Fuel consumption Rate(g/kw. h) | ≤ 280 |
| Lub-oil capacity(L) | 1.65 |
| Lubricating method | Pressure and splash combined |
| Crankshaft Direction | Clockwise from flywheel end |
| Starting method | Recoil manual start or electric start |
| Overall dimensions(L× W× H) (mm) | 500× 475× 550 |
| Dry weight(kg) | 48(recoil) 53(electric) |
YL-188F
1, Enough 12 Hp
2, Bore*Stroke: 88*75mm
3, Good quality and good price
4, It is the perfect one you want to find
2, Bore*Stroke: 88*75mm
3, Good quality and good price
4, It is the perfect one you want to find
