Flexible fiberglass rod/ PIPELINE INSPECTION equipment /Durable pultrusion fiberglass duct rod
FRP cable laying tools are selected as special tools for holding electric cable and optical fibre cable in telecom and power industries. Smooth and full of elasticity surface can make the fiberglass duct rodder easily through the narrow passage.
Fiberglass duct rodder consists of three parts: Copper, glass fiber reinforced, high pressure low density polyethylene protective layer(smooth and strong, can be resistant to bad environment). Copper conductor article make fiberglass duct rodder can be easily placed in different ways.
Details:
- Outer protect layer are made of high density polyethylene and import material.
- Inner Core is E-Glass Fiber.
- Rod material is FRPI import solid core material.
- There are a lot of rod colors to choose.
Technical data:
Specification | Rod Diameter (mm) | 4.5~16 mm |
| Rod Length (m) | 30-300m |
Material: | Rod inner, | Fiber glass |
| Exterior coating | High Density polyethylene |
| Iron Frame (reinforced) | Spray coating |
| Wheel | Rubber |
| Brake | Yes |
| Drawing head | Copper |
| Working environment | -40°C to +80°C |
| technology: | Pultrusion |
Packing | Inside | plastic woven strip wind around the frame |
| Outside | carton |
Color | yellow, white, blue etc | |
Duct rodder advantages:
- High Density polyethylene (Grade: For the insulating and jacketing of Telecommunication Cables) is used in the outer diameter coating. Duct Rodders will equipped with different size reel according to the length of rod. There are wheels on the reel, which make it convenient for moving. Light weight, durable, resistance to acid, alkali, aging resistant, corrosion resistant.
- High tensile strength and bending properties, which make it to go through narrow pipes easily. Good temperature adaptability, the product will not soften in hot weather / nor become brittle in cold weather. Its usability will not be affected by temperature.
- Outer protect layer are made of high density polyethylene engineering plastic, which has good anti-UV capability. Cover was coated with long-term UV-resistant polyethylene.
Our Fiberglss Duct Rodder cages have been designed to be lighter weight for easy handling in the field. They feature sturdy construction and a hand-operated wheel brake. They can be used on their side as well as upright. Cage sizes are matched to suit the rod you order.
- Our usual packing material is carton or plastic.While if your order quantity quit considerable,we will adjust according your need.
- Usually we will delivery the produc 15 days later after your payment.But considering your practical situation,we will make our best to satisfy your request.
Anyway we will do our best to satisfy consumer's need.
- Our produ:cts use non-alkali glass fiber as the inner core, coupled with high density polyethylene and imported material as the outer protective layer, high quality and low price.
- We will give you the best quality service.
