Specifications
Plastic Pall Ring1.Low pressure drop,
2.Big flux,high efficiency
3.Used for seperation and absorption
Filtering the Waste Gas Plastic Pall Ring
Plastic Pall ring is most suited in low pressure drop, high capacity applications, lpw mass-transfer unit height ,high flooding point ,uniform gas-liquid contact ,small specific gravity,high mass transfer efficiency and so on .
Performance of Plastic Pall Ring:
Plastic Pall Ring Good Capacity and Low Pressure Drop
- Higher capacity and lower pressure drop than ceramic packing.
- Multiple sizes provide ability to optimize capacity and efficiency based on application requirements.
Plastic Pall Ring Higher Liquid Hold-up and Residence Time
- Relatively high liquid hold-up allows good absorption efficiency with slow chemical reaction.
Plastic Pall Ring Versatile Standard Packing
- Lower sensitivity to liquid and vapor distribution quality allows use with conventional liquid distributors.
Plastic Pall Ring High Mechanical Strength
- Ring and spoke construction provides high mechanical strength, which allows use in deep beds.
Material: polypropylene, strengthens polypropylene, strengthen nylon6, strengthen PBT
Technical Parameter of Plastic Pall Ring :
Name |
Size |
Diameterx Height x Thickness |
Surface area |
Void space |
Bulk density |
No.per |
Packing factor |
Pall ring |
25 |
25x25x1.2 |
213 |
91 |
85 |
48300 |
285 |
38 |
38x38x1.4 |
151 |
91 |
82 |
15800 |
200 |
|
50 |
50x50x1.5 |
100 |
92 |
60 |
6300 |
130 |
|
76 |
76x76x2.6 |
72 |
92 |
62 |
1930 |
92 |
More Pictures of Plastic Pall Ring :
