Specifications
Muti-faced Hollow Ball1.20 years professional manufacturer
2.Size:25,38,50,76,100
3.Material:PP,PE,PVC,PVDF
Polyhedral hollow ball as Mass Transfer Media/ Muti-faced Hollow Ball
Multi-Surface Hollow Ball Pilling Material is made of Polypropylene ethylene plastic in ball shape. There is a reinforcing ring in the middle of the ball alomg the round cycle, which divides the ball two side. Each side has 12 pieces of ball clacks.
The Advantages of Muti-faced Hollow Ball :
- High free volume
- Low pressure drop
- Low mass transfer unit height
- High flooding point
- Uniform gas-liquid contact
- Small specific gravity
- High mass transfer
Applications of Muti-faced Hollow Ball :
- Gas absorption,Deabsorption system, Scrubbing tower, Removing smoke equipment
- Application temperature in media ranges from 60 to 150 degrees
Physical & Chemical properties of Muti-faced Hollow Ball
Performance / Material |
PE |
PP |
RPP |
PVC |
CPVC |
PVDF |
Density (kg/m3) |
0.94-0.96 |
0.89-0.91 |
0.93-0.94 |
1.32-1.44 |
1.50-1.54 |
1.75-1.78 |
Operation Temp.(Degree C) |
90 |
>100 |
>120 |
>60 |
>90 |
>150 |
Chemical corrosion resistance |
Good |
Good |
Good |
Good |
Good |
Good |
Compression Strength(Mpa) |
>6.0 |
>6.5 |
>7.0 |
>6.0 |
>8.0 |
>10.0 |
Technical Data for Muti-faced Hollow Ball
Specification (mm) |
Surface area (m²/m³) |
Free volume (%) |
Bulk density (kg/m³) |
Number per m³ |
ø25 |
460 |
84 |
145 |
64000 |
ø38 |
325 |
87 |
125 |
25000 |
ø50 |
236 |
90 |
105 |
11500 |
ø76 |
150 |
92 |
90 |
3000 |
Package Type |
Container Load Capacity |
Delivery time |
Quality Insurance |
Payment Terms |
||
20 GP |
40 GP |
40 HQ |
||||
Ton bag |
20-24 m3 |
40 m3 |
48 m3 |
Within 3-10 days |
Chinese National Standard; Offer quality assurance as request. |
T/T, L/C, Paypal, West Union |
Plastic bag |
25 m3 |
54 m3 |
68 m3 |
|||
Paper box |
20 m3 |
40 m3 |
40 m3 |
|||
