Specifications
hot sale quantitative charcoal weighing and packing machine1.high accuracy
2.Packing speed:3-4bags/min
Weighing: 1-5kg/ba
hot sale charcoal quantitative weighing and packing machine
Main engine control:
1.Viewing screen PLC control instrument.
2.It adopts fast,medium and slow converter control the screw rotation blanking.
3.It has the information memory function about class output,day output and cumulative production.
Technical parameter:
Model |
BZJ-50KG |
Weighing ability |
3-4bags/min |
Weighing scope |
1-5kg/bag |
Weighing error |
±0.3% |
Main engine power |
2.2kw |
Voltage |
AC380v |
Pressure force |
0.4---0.5MPa |
Control method |
PLC microcomputer |
Air quantity |
0.4Nm3/min |
Overall dimension |
2.6*1.6*2.65m |
Material |
Carbon steel |
Conveyor:
Technical parameter:
Conveyor length |
Conveyor width |
Max.transport capacity |
Voltage |
Power |
2.2m |
400mm |
15bags/min |
AC380v |
0.75kw |
Sewing machine:
Technical parameter:
Model |
YHGK3-18 |
Max. Sewing speed |
1700 needle/min |
Stitch length |
6.5-11mm |
Max. Sewing thickness |
8mm |
Needle tracking form |
Double chain |
Suture specification |
21S/5,20S/3 Terylen yarn,30S/ cotton |
Needle model |
80800, 200-250# |
Voltage |
AC380v |
Power |
0.55kw |
