Specifications
pillow type packaging machine1.self-diagnostic function
2.Temperature independent PID control
duable TH-320 pillow type packaging machine
technical parameter:
type |
THB-280 |
THB-320 |
THB-380 |
Packaging film width |
100-280mm |
110-320mm |
120-380mm |
Bag length |
80-300mm |
90-300mm |
100-300mm |
Product Height |
5-40mm(40mm above according to you customer requirements) |
5-40mm(40mm above according to you customer requirements) |
5-50mm(40mm above according to you customer requirements0 |
Film roll diameter |
≤320mm |
||
Packing speed |
30-280 bags/min |
30-280 bags/min |
30-280bags/min |
Power Specifications |
220V50HZ 2.5kw |
220V50HZ 2.8KW |
220V50HZ 3KW |
Machine size |
(L)4000×(W)900×(H)1500mm |
(L)4000×(W)900×(H)1500mm |
(L)4100×(W)950×(H)1520mm |
Total weight |
500kg |
560kg |
600kg |
Main performance and structural characteristics
1, stepper motor control servo motor (optional), bag length can be set and cut, without air conditioning in one step, saving time and film.
2, the man-machine interface, convenient parameter setting.
3, self-diagnostic function, clear failure display.
4, sensitivity photoelectric eye tracking, digital input cut position make the sealing position more accurately.
5 Temperature independent PID control, more suitable for packing material.
6 Positioned stop function, without sticking knife or wasting film.
Powertrain simple, the work is more reliable, and easier maintenance.
8, all the controls are achieved by software, convenient for function adjusting and technical upgrade and maintain advanced.
(B) Scope suitable for moon cake, ice cream, rice, snow cake, pie, Sachima, chocolate, candy, bread, instant noodles, biscuits, medicines, daily necessities, industrial parts, paper box or trays, and other various types of rules objects packaging.
