Home > Industrial Equipment & Components > Valve > Ball Valve > Class 150-2500 Cast Steel Swing Check Valve

Class 150-2500 Cast Steel Swing Check Valve

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Standard or Nonstandard:

Standard

Structure:

Check

Pressure:

High Pressure

Contact Supplier Request Quote Chat Now

Yongjia Welldone Machine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Standard or Nonstandard Standard

Structure Check

Pressure High Pressure

Power Hydraulic

Material Casting

Temperature of Media High Temperature

Media Water

Place of Origin Zhejiang, China

Model Number Check Valve

Brand Name WD

Specifications

Cast Steel Swing Check Valve
1.DN:40-500MM
2.PN:1.0,1.6,2.0,4.0.6.4
3.Medium:gas,oil ,water.
5.Material:cast iron ,wcb.etc

Class 150-2500 Cast Steel Swing Check Valve

Class150-2500 cast steel swing check valve

1. Design and manufacture of product according to American state standard ANSI B16.34, American petroleum institute standard API6D.
2. Small opening pressure, the disc can be opened fully with a very small pressure differential.
3. Rocker and hinge pin use inside-set design, reduces outer leakage point.
4. The body and bonnet of class 1500~Class 900 check valve is connected with stud. And the body and bonnet of class 1500~class 2500 check valve pressure seat structure to make product bulk small, weight light, seal credible.

STD (Fire-proof,electricity Protect)

Type	Design And Manufacture	Face to face/End to end	Flange Dimension	Pressure and Temperature	lnspection and test
Swing check valve Lift check valve	APl6D BS1868	ASME B16.10	ASME B16.5	ASME B16.34	APl 598

Pressure test

Nominal Pressrue	Shell Test		Water Seal Test		Air Seal Test
Nominal Pressrue	MPa	Lbf/in2	MPa	Lbf/in2	MPa	Lbf/in2
150	3.1	450	2.2	315	0.5-0.7	60-100
300	7.8	1125	5.6	815
600	15.3	2225	11.2	1630
900	23.1	3350	16.8	2440
1500	38.4	5575	28.1	4080
2500	64.6	9367	47.4	6873

Main part material

Body	ASTM A216 WCB				ASTM A351 CF8
Disc and Yoke	WCB	CF8	CF8M	Monel	ASTM A351 CF8
Hinge pin	F6a	F304	F316	Monel	F304
Disc face	13Cr 13Cr STL	304 STL	316 STL	Monel	304 304 STL
seat ring face	13Cr STL STL	304 STL	316 STL	Monel	304 304 STL
Body	ASTM A351 CF3 ASTM A351 CF8M ASTM A351 CF3M
Disc and Yode	ASTM A351 CF3 ASTM A351 CF8M ASTM A351 CF3M
Hinge pin	F304L F316L F316L
Disc face	304L 304L STL		316 316 STL		316L 316L STL
seat ring face	304L STL STL		316 STL STL		316L STL STL
