Class 150 Carbon Steel Ball Valve -2,carbon Steel Ball Valve

Class 150 Carbon Steel Ball Valve -2,carbon Steel Ball Valve thumbnail-1
Class 150 Carbon Steel Ball Valve -2,carbon Steel Ball Valve photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Other, carbon steel ball valve
Pressure:
Medium Pressure
Contact Supplier Request Quote Chat Now
Yongjia Welldone Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Standard or Nonstandard Standard
Structure Other, carbon steel ball valve
Pressure Medium Pressure
Power Manual
Material Forged
Temperature of Media Normal Temperature
Media Other, gas, oil, water, steam
Port Size 1/4"--4"
Place of Origin Zhejiang, China
Model Number ball valve
Brand Name WD

Specifications

carbon steel ball valve
1.Flanged end
2.Trunnion Mounted type
3.Two pieces body
4.API certificate

Class 150 carbon steel ball valve  -2,   carbon steel ball valve Class 150 Carbon Steel Ball Valve -2,carbon steel ball valveClass 150 Carbon Steel Ball Valve -2,carbon steel ball valveClass 150 Carbon Steel Ball Valve -2,carbon steel ball valve

Class150 cast steel trunnion type ball valve
Characteristics of API Ball Valve
1. Design and manufacture of product according to American state standard ANSI B16.34, American petroleum institute standard API608 API6D.
2. Liquid resistance smallest of all type of valve.
3. Open quickly, only turn on 90 degree may finish open and close.
4. Seat material use teflon or R-teflon, low friction, seal reliable open and close lightly.
5. Movement of ball on the middle of valve seat has wipe function so may suit medium of suspending granule.
6. Stem use back seal and hyperbatic structure which may prevent medium to striking stem on the condition of pressure.
7. According to the need of consumer, may design for anti-static electricity, fireproof and use a locker to prevent wrong operator.
8. Body of ball can be floated or fixed accordance with the of strength of opening and closing. Seat of fixed ball valve floatable realize seal purpose depend on piston effect of medium pressure so to lighten the strength of open and close.



STD (Fire -Proof,Electricity Protect)

Type Desing And Manufacture Face to face /End to end Flange Dimension Pressure and Temperature lnspection and test
Split flange ball valve BS5351 API6D ASME B16.10 ASME B16.5 ASME B16.34 API598
Fixed flange valve API6D

Pressure Test

Nominal Pressure Shell Test Water Seal Test Air Seal Test
MPa Lbf/in2 MPa Lbf/in2 MPa Lbf/in2
150 3.1 450 2.2 315 0.5-0.7 60-100
300 7.8 1125 5.6 815
600 15.3 2225 11.2 1630
900 23.1 3350 16.8 2440
1500 38.4 5575 28.1 4080
