New Designed Backhoe Loader
Key points:
1. Rated load:2500kg;
2.Bucket capacity:1.3m3;
3.Engine: YC 4015;
4. Power: 85kw / 2400rpm;
5.Backhoe capacity:0.3m3.
........
Specification details:
| Basic datas | Rated Loading | 2500kg |
Bucket Capacity | 1.3-1.5m3 | |
Wheel base | 2200mm | |
Min. Ground Clearance | 300mm | |
Breakout Force | 38KN | |
Bucket Dumping Height | 3500mm | |
Bucket Dumping reach | 1106mm | |
Backhoe Capacity | 0.3 m3 | |
Max. Digging Depth | 4016mm | |
Swing Angle of Excavator Grab | 190 degree c. | |
Max. Pulling Force | 39KN | |
Dimension(L*W*H) | 7150*2300*3360mm | |
Overall Operating Weight | 8100KG | |
| Engine | Model | YC4015 |
Type | In Line Direct injection Four-Stroke | |
Cylinder-Inside Diameter*Stroke | 4-110*120 | |
Rated Power | 85KW | |
Rated Speed | 2400r/min | |
Min. Fuel Consumption | ≤216g/km.h | |
Max.Torque | ≥261.7N.M/1800r/min | |
Displacement | 4.4L | |
| Steering system | Model of Steering Device | BZZ5-250 |
Steering Angle | ±36 degree | |
Min. turning radius | 6581mm | |
Pressure of the system | 12Mpa | |
| Axle | Origin | Feicheng Axle Factory |
Main Transmission Type | Double Reduction | |
Final Reducer | Single Stage Final Reducer | |
Rated Loader of Axle | 4/18.5t | |
| Torque converter | Model | YJ315 |
Type | Single-stage Three Elements | |
Max. Efficiency | 88.4% | |
Inlet Pressure | 0.4Mpa-0.55 Mpa | |
Outlet Pressure | 1.2Mpa-1.5 Mpa | |
Cooling Method | Oil-cooling Pressure Circulation | |
| Gearbox | Type | Power shift normally engaged straight gear |
Oil Pressure of Clutch | 1373kpa-1569 kpa | |
Gear shift | 4 forward shift 4 reverse shift | |
Max.Speed | 38Km/h | |
| Hydraulic datas | Digging Power of Excavator Grab | 46.5KN |
Digging Power of Dipper | 31KN | |
Bucket Lifting Time | 5.4S | |
Bucket Lowering Time | 3.1S | |
Bucket Discharge Time | 2.0S | |
| Brake system | Service brake | Over Oil Caliper Brake |
External Type | ||
Self-regulation | ||
Self-balance | ||
Emergency Brake | Operation Power Implementing brake | |
Manual Operation Power Terminating Brake | ||
| Tyre | Model | 16/70-20 |
Pressure of Front wheel | 0.22 Mpa | |
Pressure of Back Wheel | 0.22 Mpa | |
................
...................................
