Hydraulic Stationary Scissor Cargo Platforms are widely used machines for many fields, the most popular using are in warehouse,basement, first floor,etc, which for carrying the cargos,cars,,etc. to the high floors. Both inside and outside using available.
It's design and produce as clients' requirements, as long as telling us the requirements of capacity, platform size, lifting height, we can design, supply drawing and give offer.
...............
Following are specifications of model SJG1-4.4, it is used for goods carrying from basement to ground floor, or to high floors.
Model |
SJG1-4.4 |
Capacity: |
1000kg |
Lifting height: |
4400mm |
Platform size: |
2200*2100mm |
Closed height: |
850mm |
Net weight: |
2000kg |
Package: |
Wooden case, size about: 2.3*2.2*1.1m, 2300kg. |
Cylinder: |
Φ90*2pcs |
Main material: |
160*80*5mm steel tube |
Upper frame: |
14# heavy steel |
Platform thickness: |
5mm checkered plates |
Handrail height : |
1000mm, 4pcs |
Power: |
3KW/380V/50hz |
Spare parts: |
Oil pipes and seal ring |
...............
The following are the models which designed for clients, please have a look for your reference:
