No dig demarcation site construction hoarding temp fence
Construction hoarding temp fence is very popular in Canada, North America, the frame is square pipe.
The surface treatment of construction hoarding temp fence is hot-dipped gal+pvc/power spayed,which is anti-acid and anti-alkali in the outdoor environment and prolong life time.
Construction hoarding temp fence is used for fencing off construction and industrial sites and events. They protects against theft and vandalism, keep children and unwanted persons out of dangerous site and enables access control of visitors to events.
Specification of construction hoarding temp fence
1)Column and mesh technology parameter
Raw material performance |
mesh wire tensile strength:Mpa |
500—550 Mpa |
column plate tensile strength:Mpa |
≥400 Mpa |
|
column steel strip elongation:% |
26%≤elongation≤40% |
|
Grid solder joint tensile resistance(N) |
mesh |
3000-5000 N |
2)Common size
Wire diameter |
3mm,2.5mm,4mm(popular),4.5mm,5mm
|
Mesh of the fence panel |
60mmx120mm,60*150mm(popular),50mmx100mm,50mmx200mm, 100mmx100mm, 75mmx75mm
|
Width& length |
2500mmx1800mm, 2000mmx1800mm 2100mmx2400mm(popular), 1800*2900mm, 2100*2600mm 1800*2400mm or as your requirements.
|
Frame & rail |
Round pipe: 25mm, 32mm(popular),42mm,48mm O.D The normal thickness is 1.5-2.0mm,2.0mm is the most popular
|
Support post |
Round Pipe diameter: 40mm 42mm 48mm 60mm
|
Surface treatment |
Hot dipped galvanized Or Paited
|
Fence foot |
Plastic bases filled with concrete (600x220x150mm)
|
1.Secure-nett Technology:
1)Raw Material
Construction hoarding temp fence frame uses hot-dipped galvanized steel sheet as raw material,which is strong corrosion resistance,good surface quality,uniform galvanized layer and conductive to processing.
Wire for panel,which adopts high quality low carbon hot-dipped galvanized steel wire with tensile strength above 450N to 500N.
2)Welding equipment adopts the most advanced domestic automatic welding machine.The equipment adopts synchronous control technology;points in welding and welding time control are controlled by PLC digital programming system with touch screen input panel makes operation more intelligent.
3)Produce line
4)Surface treatment
Four layers surface coating treatment:
1. Hot-dip galvanizing: Extra protection against rust, corrosion;
2 Zinc phosphate: Promote the adhesion between the steel and coating film;
3. Zinc-rich epoxy powder coat: Providing long-lasting, anti-impaction and anti-corrosion;
4. Polyester color coat: With extra anti-UV rays, corrosion and self-cleaning
Electrostatic spraying polyester equipment
Our company is the only one enterprise who purchases ITW GEMA electrostatic spraying polyester equipment for fence surface treatment in fence industry.To achieve ideal electrostatic spraying polyester effect,our spraying power adopts AKZO NOBEL,which manufacturer is one of the world's top 500 enterprise.It is the largest polyester power provider in the world.
- Packaging&Shipping
It has rubber mat at the bottom of the pallet to avoid the pallet destroyed the panels.
It has 4 metal corners to keep the pallet more strong.
It has metal plate under the plastic bandage to reduce the apressure of fence panels.
wooden plate on top which can protect the fence panels avoid being crushed by other pallets.
1.15 days after receive the deposit payment.
2.We will choose high quality and low price od the shipping company.
3.Loading the goods,we will track all the way,to ensure product safety,quick to arrive at the
designated ports.
4.Company for products and accessories ,for a long time to be able to provide various products accessories at
cost to the customer at any time.
Company Introduction
Hebei SECURE NET Fence Facility Co., Ltd. is committed to professional and comprehensive site protection product development and production, providing global customers with high-quality advanced metal fences, gates and other protective all steel products and services. We insist on providing high-quality products to every custom is our consistent goal,and with 10 years of experience,we will find the best way to solve any problem for clients.
By now, our business has extended to many areas in China like Beijing, Tianjin, Chongqing, Fujian, Sichuan, Mongolia and so on. And also, we export our goods to America, Australia, Germany, Italy and more than 30 countries and areas.
Enterprise Culture
Promises must be kept and action must be resolute.
Result is the first,excuse is the second.
Efficiency first,success or failure second.
Office building
Indoor
Workplace
If you are interested in our products or some questions,please feel free ask me.
