12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller

12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller thumbnail-1
12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller thumbnail-2
12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller thumbnail-3
12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller photo-1
12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller photo-2
12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller photo-3
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Single Drum Roller
Static Linear Pressure:
303N/cm
Contact Supplier Request Quote Chat Now
Nivo Machinery (Jingjiang) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Single Drum Roller
Static Linear Pressure 303N/cm
Travel Speed 11km/h
Grade Ability 40%
Place of Origin Jiangsu, China
Brand Name LUOYANG
Model Number LSS1201H
Power(W) 97kW
Dimension(L*W*H) 6000*2280*2995mm
Weight 12000kg
Certification CE,ISO,OHSMS,EMS
After-sales Service Provided Overseas third-party support available



Product Description

  12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller



12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller

Hydraulic vibratory rollers are suitable for compaction of non-cohesive materials such as gravel, crushed stone, sand-macadam mixture, sandy soil and rock filling etc. on base course, sub-base and embankment fill construction etc., which are ideal equipment for high-class highway, railway, airport, harbors, dams and large-scale industrial ground etc.





Main Features



1.Cummins air-air after-cooled diesel engine with EURO-2 and CHINA-3 emission standards.

2.Hydrostatic wheel&drum travel drive with stronger traction and gradeability capacity.

3.New types of vibration device and drum travel bearing structure with strong vibrating drum and excellent lubracation.

4.National patented the Forward Output and torsioning Connection to the Vibrating Pump.

5.Service brake with hydraulic colsed self-lock function; Parking/Emergency brake with off-oil braking(SAHR).

6.National patented latest style of engine hood; The vibrating pump and braking booster behind the machine for convenient maintenance.

7. MP3 vehicle audio device with USB and SD socket.







Technical Specifications

Type Unit LSS1201H
 Operating mass  kg  12000kg
 Static linear load  N/cm  303
 Vibration amplitude  mm  1.8/0.9
 Vibration frequency  Hz  33
 Centrifugal force  kN  300/160
 Travel speed  km/h  11
 Gradeability  %  40
 Turning radius  mm  7000
 Drum width  mm  2130
 Drum diameter  mm  1490
 Wheelbase  mm  3230
 Ground clearance  mm  410
 Diesel engine model    Cummins6BTAA5.9
 Diesel engine power  kW  97
 Overall dimensions  mm  6000*2280*2995





Detail photos

12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller 12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller

12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller 12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller

12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller 12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller

12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller 12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller

Optional part: Intergrated padfoot drum

12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller

Packaging & Shipping

 12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller

Certifications

12 Ton CE Certificate New Types Hydraulic Single Drum Vibratory Compactor Roller
