Walking tractor(15HP)

Model

AMEC-12L

AMEC-15L

Structure weight KG

Without rotavator

353

363

With rotavator

458

468

Working weight (with rotavator) KG

493

508

Overall dimensions (LxWxH)  mm

2680 x 960 x 1250

Number of blades PCS

18

Rototilling width mm

600

Type of tractor

Single axle, dual-purpose for both traction & drive

Travelling speed Km/h Forwrd

1.4,2.5,4.1,5.3,9.4,15.3

Travelling speed Km/h  Reverse

1.1, 3.8

Type size

6.00-12

Wheel track mm

800, 740, 640, 580(normally use 800)

Min. ground clearance mm

185

Min. turning radius m

0.9 with no rotavato

Model of engine

S195N

S1100N

Type of engine

Horizontal 4-stroke

Bore x stroke mm

95×115

100×115

Total displacement L

0.815

0.903

Compression ratio

20:1

19.5:1

Turing speed of crankshaft rpm

2000

1-hour rated output KW/hphp

9.3/12.65

10.5/14.3

12-hour rated output KW/hp

8.3/11.29

9.8/13.33

Specific fuel consumption g/kw.h

≤258

≤250

Specific lube oil consumption g/kw.h

≤2.04

≤2.00

Cooling mode

Condenser (Radiator)
