Diesel Engine R Series(single Cylinder,water Cooled)

Name: Diesel Engine R Series(single Cylinder,water Cooled)
Brand: AMEC
SKU: 140840140
Availability: InStock

Changzhou Machinery & Equipment Imp.&Exp. Co., Ltd.

US$ 60 - 200 MOQ: 100 Sets

Key Specifications

Condition:

New

Usage:

Other, Agricultural machines

Fuel:

Diesel

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Usage Other, Agricultural machines

Fuel Diesel

Stroke 4 Stroke

Cylinder Single Cylinder

Cold Style Other, Water-cooled

Start Electric Start

Place of Origin Jiangsu, China

Brand Name AMEC

Model Number R180/R170

Dimension(L*W*H) 640*380*550mm

Weight 35-100Kgs

Certification ISO9001:2008

Warranty One Year

After-sales Service Provided No overseas service provided

	R165	R170	R170B	R175B	R180	ZR180	R185	ZR185	R190	ZR190
Engine type	Single cylinder,horizontal,water-cooled,4-stroke
Combustion chamber	Swirl					Direct injection	Swirl	Direct injection	Swirl	Direct injection
bore(mm)	65	70		75	80		85		90
Stroke(mm)	60		65	80	80		90
displacement (L)	0.199	0.231	0.250	0.353	0.402		0.511		0.573
Rated power/speed(kW/ r/min)	2.43/2600	3.0/2600	3.64/3000	4.85/2600	5.67/2600		6.47/2200	6.8/2300	7.7/2300
Max. torque(N.m)	/				23.4		31.5		35.8
Speed at Max. torque(r/min)	/				2080		1760	1840
Fuel consumption (g/kw.h)	307.4	296.5	296.5	280.2	278.8	255	274.7	260	265.2	255
Compression ratio	22				21	19.5	21	19.5	21	19.5
Starting system	Hand cranking				Hand cranking or electric
Net weight(Kg)	29	31		60	72		95		100
Overall dimension (LWH) (mm)	473282365		473280365	589342463	625341464		670381560
