Specifications
3 point hitch backhoe:1. 3-point hitch, hydraulic backhoe
2. LW-6, LW-7, LW-8, LW-12 models
3. Matching 20HP~145HP tractors
3 point hitch backhoe LW-6, LW-7, LW-8 specifications:
Items | Unit | LW-6 | LW-7 | LW-8 |
Max. digging depth | mm | 1850 | 2150 | 2640 |
Digging depth at flat 2-inch bottom | mm | 1600 | 2000 | 2500 |
Max. digging height | mm | 2500 | 3400 | 3510 |
Offloading height | mm | 1400 | 1760 | 2000 |
Shipping height | mm | 1733 | 1878 | 1952 |
Ground clearance | mm | 280 | 290 | 290 |
Boom pin height | mm | 420 | 500 | 500 |
Vertical digging depth | mm | 895 | 1134 | 1446 |
Max. digging radius | mm | 2800 | 3360 | 3930 |
Offloading distance | mm | 1044 | 1187 | 1945 |
Bucket rotation angle | ° | 160 | 160 | 160 |
Swing angle | ° | 140 | 140 | 140 |
Heavy duty 3-point hitch hydraulic backhoe LW-12 specifications:
Backhoe model | LW-12 |
Matching tractor (HP) | 120~145 |
Max digging depth (mm) | 3600 |
Max unloading height (mm) | 3200 |
Max digging height (mm) | 4500 |
Max digging depth flat bottom (mm) | 3500 |
Max swing angle | 180 |
Bucket rotating angle | 174 |
Bucket capacity (CBM) | 0.2 |
Weight (KG) | 1050 |
Its used for ditching in farms and grazing lands, digging pool, cleaning waterways as well as assistant excavating work in construction and building roads.
Hydraulic transmission is used, featured with compact structure, flexibility, convenient operation and quick mounting and dismounting. It uses hydraulic oil commonly with tractor. The hydraulic elements are standardized, convenient for operation and service.
To better accomplish different kinds of work, buckets of different sizes can be selected and mounted on it.
