6.000.000 Mpa.s Precise Viscometer for Solder Paste

Negotiable MOQ: 1 Box (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

Model Number:

NDJ-9S

Changzhou W&J Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai or other

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name WJ

Model Number NDJ-9S

Power Electronic

Usage Auto Testing Machine

6.000.000 mpa.s precise viscometer for solder paste

Model	9S
Measurement Range	1-6×10⁶mpa.s
Display	LCD
Spindles Specification	No. 1, 2, 3, 4( NO. 0 is optional) Note: The bigger the number of the spindles, the bigger the measuring value
Rotating Speed of Spindles	0.1/ 0.3 / 0.6 / 1.5 / 3 / 6 / 12 / 30 / 60 rpm/min
Interface	No
Automatic Switch	free selection of proper rotating speed or Spindles number.
Stable Cursor	Strip-type cursor fully charged displayed when reading basically stable
Measurement Tolerance	± 3%
Power	AC 220V ± 10% 50 Hz ± 10%
Working Condition	Temperature 5-35 degree Relative humidity no more than 80%
Attachments	l No. 1,2,3,4 Spindles l (No. 0 Spindles is optional, if need, please contact with me.) l Adapter l Protection Frame l Foundation Plate l Up-Down Frame l English Manual l Hexagonal Spanner l Solid Wrench
Outline Dimension (mm)	370×325×280 mm
Packing (mm)	400×360×310 mm
Net Weight (kg)	6.8 kg
Gross Weight (kg)	9 kg
Min. Order	1 pc by Air or 10 pcs by Ship
Delivery Date (<10 pc)	Within 1 Week After Receiving Payment
H.S. Code	9027
