Digital Orbital and Linear Shaker
1. Compact, orbital shaker with ideal swivel motion, for a maximum shaking weight of 7.5kg
2. LCD display for speed and time adjustment, makes it possible to read the speed, timer function and operating mode
3. Wide range of attachment combinations makes it possible to use almost all shapes and sizes of vessels
4. Electronic adjustment of speed and timer
5. Electronic time switching clock: time or continuous operation mode 5, Outer rotor brushless motor 6. Linear shaker optional
7. Over speed detection and protection
8. PC control via RS232 interface, software is available to control and document all measuring values via PC. Parameter can be set to carry out safety monitoring
Date Description |
WAO-180 |
WAL-180 |
WAO-300 |
WAL-300 |
Voltage |
100-240V |
|||
Frequency |
50/60HZ |
|||
Power |
30W |
|||
Shaking movement |
Orbital |
Linear |
Orbital |
Linear |
Orbital diameter |
4mm |
10mm |
||
|
Max shaking weight (with attachment) |
2.5Kg |
7.5Kg |
||
Motor Type |
External rotor brushless motor |
|||
Motor rating input |
28W |
|||
Motor rating output |
15W |
|||
Speed Range |
100-800RPM |
100-500RPM |
||
Speed display |
LCD |
|||
Timer |
YES |
|||
Timer display |
LCD |
|||
Time setting range |
1-1199min |
|||
Run type |
Time/Continuous operation |
|||
Overall dimensions (DxWxH) |
340x300x100mm |
420x370x100mm |
||
Weight |
8.1Kg |
13.5Kg |
||
Permissible ambient Temp |
5-40℃ |
|||
Permissible relative humidity |
80% |
|||
Protection class to DIN EN60529 |
IP21 |
|||
RS232 interface |
YES |
|||
Optional Parts
Model Number |
Description |
|
SK180-1 |
SK 180.1 Universal attachment |
|
SK180-2 |
SK 180.2 Fixing clip attachment |
|
SK180-3 |
SK180.3 Lengthways Roller Attachment |
|
SK180-4 |
SK180.4 Dish Attachment (with slip-resistant foil) |
|
SK330-1 |
SK 330.1 Universal attachment |
|
SK330-2 |
SK 330.2 Fixing clip attachment |
|
SK330-3 |
SK330.3 Lengthways Roller Attachment |
|
SK330-4 |
SK330.4 Dish Attachment (with slip-resistant foil) |
|
SK180-21 /SK330-21 |
Fixing Clip For flask volume 25 ml |
|
SK180-22 /SK330-22 |
Fixing Clip For flask volume 50 ml |
|
SK180-23 /SK330-23 |
Fixing Clip For flask volume 100 ml |
|
SK180-24 /SK330-24 |
Fixing Clip For flask volume 200/250 ml |
|
SK180-25 /SK330-25 |
Fixing Clip For flask volume 500 ml |
|
Bar for SK330-1 Universal attachment, black |
||
Bar for SK180-1 Universal attachment, black |
