Hot Sell Gasoline Engine Small Gasoline Engine JD1000 & JD1200 (2.4/3600 HP/rpm & 4-stroke & Single Cylinder & Air-cooled)

Specification

GENERATOR

Model

JD1000

JD1200

Type

Brush, Brushless Single-Phase

Voltage Regulate

AVR/Capacitor

Frequency Hz

50/60

Rated AC Voltage (V)

110V/120V/220V/230V/240V

Rated AC Output (KVA)

0.9/1.0

1.0/1.1

Peak AC Output  (KVA)

1.0/1.1

1.1/1.2

Power Factor   COSφ

1.0

ENGINE

Model

JF154

Type

4-stroke,  single cylinder with Air-cooled

Bore x Stroke   (mm/inch)

54×38.5/2.13×1.52

Displacement  (ml)

86.5

Max. output  (HP/rpm)

2.4/3600

Fuel

Unleaded Gasoline

Fuel Tank Capacity        (L/gal)

5/1.3

Continuous Operating Hours (h)

15

Oil

SF or Higher Grade

Oil Capacity      (L/gal)

0.4/0.11

Ignition system

C.D.I.

Starting  System

Recoil and hand-operated

Operating Noise Level (7m) dB(A)

68

STANDARD FEATURES

Fuel gauge

0

0

Voltmeter

0

0

Engine Switch

0

0

AC Circuit Breaker

0

0

AC  Socket

0

0

OPTIONAL FEATURES

Pilot Light

+

+

DC Output

+

+

DC Circuit Breaker

+

+

PACKAGE DIMENSIONS

Dimensions L×W×H (mm/inch)

480×410×425/18.9×16.14×16.73

Gross Weight   (kg/lbs)

69/152

77.5/171

Net Weight  (kg/lbs)

65/143

73.5/162

20/40FT   unit

335/675
